Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA5500ES
222
C8226 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8227 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8228 1-128-994-21 ELECT CHIP 47uF 20% 10V
C8229 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C8233 1-164-373-11 CERAMIC CHIP 0.033uF 25V
C8240 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C8241 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C8242 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C8243 1-119-667-11 CERAMIC CHIP 22uF 10V
C8244 1-165-669-21 ELECT CHIP 220uF 20% 6.3V
C8245 1-119-667-11 CERAMIC CHIP 22uF 10V
C8250 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C8251 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C8252 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C8253 1-119-667-11 CERAMIC CHIP 22uF 10V
C8254 1-165-669-21 ELECT CHIP 220uF 20% 6.3V
C8255 1-119-667-11 CERAMIC CHIP 22uF 10V
C8256 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C8257 1-124-779-00 ELECT CHIP 10uF 20% 16V
C8284 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8295 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8296 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C8297 1-124-779-00 ELECT CHIP 10uF 20% 16V
C8298 1-124-779-00 ELECT CHIP 10uF 20% 16V
C8299 1-124-779-00 ELECT CHIP 10uF 20% 16V
< CONNECTOR/JACK >
CN6702 1-770-411-11 CONNECTOR, BOARD TO BOARD 20P
CN6703 1-770-411-11 CONNECTOR, BOARD TO BOARD 20P
CN6751 1-817-615-21 CONNECTOR, SQUARE TYPE (RECE) (DMPORT)
CN6801 1-793-642-21 CONNECTOR (USB) (4P), SQUARE (XM)
(US, CND)
CN8001 1-784-210-21 CONNECTOR 7P
CN8002 1-770-407-11 CONNECTOR, BOARD TO BOARD 12P
CN8005 1-820-427-11 JACK, MODULAR (LAN)
CN8006 1-815-875-21 PIN, CONNECTOR (PC BOARD) (12P)
CN8200 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
< DIODE >
D6703 6-501-817-01 DIODE MA2J1110GLS0
D6704 6-501-817-01 DIODE MA2J1110GLS0
D6801 6-501-817-01 DIODE MA2J1110GLS0
D6802 6-501-817-01 DIODE MA2J1110GLS0
D6803 8-719-083-02 DIODE KDS160-RTK (US, CND)
D6804 8-719-083-02 DIODE KDS160-RTK (US, CND)
D6805 6-500-462-01 DIODE NSAD500F-T1B (US, CND)
D8003 8-719-987-69 DIODE DAN217
D8004 8-719-987-69 DIODE DAN217
D8005 8-719-987-69 DIODE DAN217
D8006 8-719-987-69 DIODE DAN217
< FERRITE BEAD/JUMPER RESISTOR >
FB6802 1-469-152-11 FERRITE, EMI (SMD) (2012) (US, CND)
FB6803 1-469-152-11 FERRITE, EMI (SMD) (2012) (US, CND)
FB8001 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB8003 1-414-234-22 INDUCTOR, FERRITE BEAD
FB8004 1-414-234-22 INDUCTOR, FERRITE BEAD
FB8006 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB8007 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB8008 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB8009 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB8010 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB8011 1-469-407-22 INDUCTOR, FERRITE BEAD
FB8012 1-469-407-22 INDUCTOR, FERRITE BEAD
FB8015 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB8016 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB8017 1-216-295-91 SHORT CHIP 0
FB8018 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB8019 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB8201 1-400-334-21 FERRITE, EMI (SMD) (1608)
FB8202 1-400-334-21 FERRITE, EMI (SMD) (1608)
FB8203 1-400-334-21 FERRITE, EMI (SMD) (1608)
< IC >
IC6751 6-711-214-01 IC TK73350WTL-G
IC6752 8-759-710-97 IC NJM4565M-D
IC6801 6-709-251-01 IC F2602E-01-TR (US, CND)
IC6802 6-702-302-01 IC TK11133CSCL-G (US, CND)
IC6803 6-707-111-01 IC PCM1753DBQR (US, CND)
IC6804 6-706-740-01 IC BA00BC0WFP-E2 (US, CND)
IC6806 8-759-710-97 IC NJM4565M-D (US, CND)
IC8001 (Not supplied) IC K9F5608U0D-PIB0T
IC8002 6-712-279-01 IC HY5DU121622DTP-D43-C
IC8003 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC8004 6-712-279-01 IC HY5DU121622DTP-D43-C
IC8005 6-704-573-01 IC M24C32-WMN6T (B)
IC8006 6-705-973-01 IC PCM1754DBQR
IC8008 8-759-710-97 IC NJM4565M-D
IC8010 8-759-710-97 IC NJM4565M-D
IC8012 6-706-606-01 IC KSZ8721BL
IC8013 (Not supplied) IC PNX1502E/G, 557
IC8014 6-708-913-01 IC TK73400AU3G0L-C
IC8015 6-713-744-01 IC NJM2580V (TE1)
IC8016 6-705-337-01 IC TK11150CSCL-G
IC8200 6-709-565-01 IC ADV7322KSTZ
IC8201 6-712-341-01 IC PCA9665PW
IC8202 6-704-261-01 IC TK11225CMCL-G
IC8203 6-702-301-01 IC TK11125CSCL-G
IC8204 6-712-366-01 IC TL16C550DPTR
IC8205 6-712-613-01 IC SI-3010KM-TLS
IC8240 6-706-136-01 IC LTC3412EFE#TR
IC8250 6-706-136-01 IC LTC3412EFE#TR
IC8251 6-707-207-01 IC SN74LVC1G3157DCKR
< COIL >
L6751 1-469-525-91 INDUCTOR 10uH
L6752 1-469-525-91 INDUCTOR 10uH
L8200 1-469-525-91 INDUCTOR 10uH
L8240 1-457-620-11 COIL, CHOKE 0.68uH
L8250 1-457-620-11 COIL, CHOKE 0.68uH
< TRANSISTOR >
Q6801 8-729-027-43 TRANSISTOR DTC114EKA-T146 (US, CND)
Q6802 8-729-027-23 TRANSISTOR DTA114EKA-T146 (US, CND)
Q6803 8-729-027-43 TRANSISTOR DTC114EKA-T146 (US, CND)
Q6804 6-550-044-01 TRANSISTOR 2SB1689-T106 (US, CND)
Q8001 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q8002 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q8003 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q8201 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q8202 8-729-027-43 TRANSISTOR DTC114EKA-T146
NETWORK
Note: IC8001 and IC8013 cannot exchange with single. When these
parts are damaged, exchange the entire mounted board.
