For Schematic Diagrams.
Note:
• All capacitors are in μF unless otherwise noted. (p: pF) 50
WV or less are not indicated except for electrolytics and
tantalums.
• All resistors are in Ω and 1/4 W or less unless otherwise
specifi ed.
•
f
: Internal component.
• 2 : Nonfl ammable resistor.
• C : Panel designation.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
• A : B+ Line.
• B : B– Line.
• H : Adjustment for repair.
• Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
– A-VIDEO board –
no mark
: VIDEO 1 mode
– Other boards –
no mark
: TUNER
• Voltages are taken with VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production
tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal production
tolerances.
• Circled numbers refer to waveforms.
• Signal path.
F : AUDIO (ANALOG)
J : AUDIO (DIGITAL)
E : VIDEO
For Printed Wiring Boards.
Note:
• X : Parts extracted from the component side.
• Y : Parts extracted from the conductor side.
•
f
: Internal component.
• : Pattern from the side which enables seeing.
(The other layers’ patterns are not indicated.)
• Lead layouts
surface
CSP (Chip Size Package) Lead layout of conventional IC
Note:
The components identi-
fi ed by mark 0 or dotted
line with mark 0 are criti-
cal for safety.
Replace only with part
number specifi ed.
Note:
Les composants identifi és
par une marque 0 sont
critiques pour la sécurité.
Ne les remplacer que par
une pièce portant le nu-
méro spécifi é.
Caution:
Pattern face side:
(Conductor Side)
Parts face side:
(Component Side)
Parts on the pattern face side seen
from the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
• D-VIDEO, DSP, F-HDMI-SATA and NETWORK boards
are multi-layer printed board. However, the patterns of
intermediate layers have not been included in diagrams.
• Indication of transistor.
C
B
These are omitted.
E
Q
B
These are omitted.
CE
Q
* Replacement of IC3601 on the D-VIDEO board used
in this set requires a special tool.
* Replacement of IC3601 on the D-VIDEO board used
in this set requires a special tool.
• Abbreviation
CND : Canadian model
• The voltage and waveform of CSP (chip size package) cannot be
measured, because its lead layout is different from that of conven-
tional IC.
• Abbreviation
CND : Canadian model
Caution:
Pattern face side:
(SIDE B)
Parts face side:
(SIDE A)
Parts on the pattern face side seen
from the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
SPTM board
TUNER (FM/AM)
A-VIDEO board
A-AUDIO board
D-VIDEO board
NETWORK board
MAIN board
E-VOL board
CONNECTOR2 board
A-CLASS AMP board
POWER AMP board
CONNECTOR1 board
PROTECTOR (SURR) board
KEY1 board
PROTECTOR (SB) board
AC board
D CONNECT board
CONTROL board
PROTECTOR (F-C) board
TEMPERATURE
DETECTION board
VIDEO2 board
MAIN VOL board
F-HDMI-SATA board
DISPLAY board
DSP board
BIAS board
CIS board
D-AUDIO board
ACSW board
DC-DC board
DCDC2 board
SPSW board
FILTER board
MIC board
• Circuit Boards Location
