Sony STR-DA7ES - Page 108

108
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R377 1-260-020-11 CARBON MELF 100K 2% 1/8W
(VA333ES)
R378 1-208-583-11 RES-CHIP 220K 2% 1/8W
(DA4ES/DA7ES)
R378 1-216-254-00 CARBON MELF 220K 2% 1/8W
(VA333ES)
R379 1-208-581-41 RES-CHIP 180K 2% 1/8W
(DA7ES)
R380 1-208-583-11 RES-CHIP 220K 2% 1/8W
(DA7ES)
R389 1-216-013-00 METAL CHIP 33 5% 1/10W
(DA4ES/DA7ES)
R390 1-216-097-11 RES-CHIP 100K 5% 1/10W
(DA4ES/DA7ES)
R391 1-216-246-00 RES-CHIP 100K 2% 1/8W
(DA4ES/DA7ES)
R392 1-249-393-11 CARBON 10 5% 1/4W
(DA4ES/DA7ES)
R393 1-216-073-00 RES-CHIP 10K 5% 1/10W
(DA4ES/DA7ES)
R394 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
(DA4ES/DA7ES)
R395 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
< RELAY >
RY301 1-755-484-11 RELAY (DA4ES/DA7ES)
*************************************************************
1-685-491-11 LED BOARD
**********
< CAPACITOR >
C118 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
* CN101 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D118 8-719-084-07 LED SEL5E20C-TP15
(MULTI CHANNEL DECODING)
< RESISTOR >
R114 1-216-073-00 RES-CHIP 10K 5% 1/10W
R115 1-216-022-00 METAL CHIP 75 5% 1/10W
R116 1-216-037-00 METAL CHIP 330 5% 1/10W
R144 1-216-073-00 RES-CHIP 10K 5% 1/10W
*************************************************************
A-4728-919-A M-BUS BOARD, COMPLETE (DA4ES/DA7ES)
**********************
< CAPACITOR >
C215 1-119-823-11 ELECT 4.7uF 20% 50V
(DA4ES/DA7ES)
C216 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
(DA4ES/DA7ES)
C232 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
(DA4ES/DA7ES)
C235 1-164-690-11 CERAMIC CHIP 0.0022uF 5% 50V
(DA4ES/DA7ES)
< CONNECTOR >
CNS204 1-568-826-11 CONNECTOR, FFC 7P (DA4ES/DA7ES)
< IC >
IC200 8-759-470-63 IC NJM2145M-TE2 (DA4ES/DA7ES)
< JACK >
J203 1-563-330-11 JACK (MONITOR IN) (DA4ES/DA7ES)
J204 1-563-330-11 JACK (TV/SAT STATUS IN) (DA4ES/DA7ES)
J205 1-563-330-11 JACK (DVD/LD OUT) (DA4ES/DA7ES)
J206 1-563-330-11 JACK (VIDEO 1 OUT) (DA4ES/DA7ES)
< TRANSISTOR >
Q200 8-729-027-43 TRANSISTOR DTC114EKA-T146
(DA4ES/DA7ES)
Q201 8-729-027-23 TRANSISTOR DTA114EKA-T146
(DA4ES/DA7ES)
< RESISTOR >
R208 1-216-049-11 RES-CHIP 1K 5% 1/10W
(DA4ES/DA7ES)
R209 1-216-049-11 RES-CHIP 1K 5% 1/10W
(DA4ES/DA7ES)
R210 1-216-049-11 RES-CHIP 1K 5% 1/10W
(DA4ES/DA7ES)
R211 1-216-049-11 RES-CHIP 1K 5% 1/10W
(DA4ES/DA7ES)
R2002 1-216-073-00 RES-CHIP 10K 5% 1/10W
(DA4ES/DA7ES)
*************************************************************
A-4728-941-A S-SPTM BOARD, COMPLETE (DA4ES/DA7ES)
A-4728-905-A S-SPTM BOARD, COMPLETE (VA333ES)
***********************
< CAPACITOR >
C613 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C614 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C615 1-137-150-11 MYLAR 0.01uF 5% 50V
C665 1-137-150-11 MYLAR 0.01uF 5% 50V
C713 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C714 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C715 1-137-150-11 MYLAR 0.01uF 5% 50V
C765 1-137-150-11 MYLAR 0.01uF 5% 50V
< DIODE >
D608 8-719-988-61 DIODE 1SS355TE-17
D657 8-719-988-61 DIODE 1SS355TE-17
D707 8-719-988-61 DIODE 1SS355TE-17
< COIL >
L601 1-422-009-13 COIL, AIR-CORE
INPUT S-SPTMM-BUSLED
