109
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
L652 1-422-009-13 COIL, AIR-CORE
L701 1-422-009-13 COIL, AIR-CORE
L751 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q602 8-729-230-49 TRANSISTOR 2SC2712-YG
Q661 8-729-230-49 TRANSISTOR 2SC2712-YG
Q707 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R616 1-249-393-11 CARBON 10 5% 1/4W
R618 1-216-073-00 RES-CHIP 10K 5% 1/10W
R619 1-249-393-11 CARBON 10 5% 1/4W
R631 1-249-389-11 CARBON 4.7 5% 1/4W
R666 1-249-393-11 CARBON 10 5% 1/4W
R670 1-249-389-11 CARBON 4.7 5% 1/4W
R682 1-216-073-00 RES-CHIP 10K 5% 1/10W
R684 1-249-393-11 CARBON 10 5% 1/4W
R716 1-249-393-11 CARBON 10 5% 1/4W
R731 1-249-389-11 CARBON 4.7 5% 1/4W
R732 1-216-073-00 RES-CHIP 10K 5% 1/10W
R734 1-249-393-11 CARBON 10 5% 1/4W
R766 1-249-393-11 CARBON 10 5% 1/4W
R781 1-249-389-11 CARBON 4.7 5% 1/4W
< RELAY >
RY651 1-515-920-11 RELAY (24V)
RY652 1-515-920-11 RELAY (24V)
RY702 1-515-920-11 RELAY (24V)
< TERMINAL >
TM701 1-694-935-11 TERMINAL BOARD (8P) (SPEAKERS,
SURROUND/SURR BACK) (DA4ES/DA7ES)
TM701 1-694-935-21 TERMINAL BOARD (8P) (SPEAKERS,
SURROUND/SURR BACK) (VA333ES)
*************************************************************
A-4728-903-A S-VIDEO BOARD, COMPLETE (AEP)
A-4728-938-A S-VIDEO BOARD, COMPLETE (DA4ES/DA7ES)
A-4728-965-A S-VIDEO BOARD, COMPLETE (TW,KR)
************************
< CAPACITOR >
C128 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C217 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C218 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C219 1-119-824-11 ELECT 10uF 20% 50V
C220 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C221 1-119-824-11 ELECT 10uF 20% 50V
C222 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C223 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C224 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C225 1-119-824-11 ELECT 10uF 20% 50V
C226 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C227 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C228 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C229 1-119-824-11 ELECT 10uF 20% 50V
C230 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C231 1-128-834-11 ELECT 470uF 20% 10V
C234 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C236 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C237 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C239 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C241 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C242 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C243 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C244 1-119-824-11 ELECT 10uF 20% 50V
C245 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(AEP)
C246 1-128-840-11 ELECT 47uF 20% 16V
(AEP)
C247 1-119-822-11 ELECT 3.3uF 20% 50V
(AEP)
C248 1-119-824-11 ELECT 10uF 20% 50V
C249 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C251 1-119-822-11 ELECT 3.3uF 20% 50V
(AEP)
C252 1-119-824-11 ELECT 10uF 20% 50V
C254 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C262 1-119-824-11 ELECT 10uF 20% 50V
C263 1-119-824-11 ELECT 10uF 20% 50V
C264 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(EXCEPT AEP)
C265 1-163-091-00 CERAMIC CHIP 8PF 50V
(EXCEPT AEP)
C266 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C267 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C268 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C269 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C270 1-128-840-11 ELECT 47uF 20% 16V
C271 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C272 1-119-824-11 ELECT 10uF 20% 50V
C274 1-119-824-11 ELECT 10uF 20% 50V
C275 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C276 1-128-840-11 ELECT 47uF 20% 16V
C279 1-126-935-11 ELECT 470uF 20% 10V
(EXCEPT AEP)
C301 1-126-965-11 ELECT 22uF 20% 50V
(EXCEPT AEP)
C302 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP)
C303 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT AEP)
C2001 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C2002 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C2004 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2006 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C2008 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2011 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2012 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C2013 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
CNP201 1-770-594-21 CONNECTOR, BOARD TO BOARD 5P (AEP)
CNP202 1-784-774-11 CONNECTOR, FFC 13P
* CNP204 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
S-SPTM S-VIDEO
