110
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CNP220 1-766-600-21 CONNECTOR, BOARD TO BOARD 7P
(EXCEPT AEP)
CNS201 1-784-774-11 CONNECTOR, FFC 13P
CNS203 1-568-826-11 CONNECTOR, FFC 7P (DA4ES/DA7ES)
< TRIMMER >
CT203 1-141-442-91 CAP, CERAMIC TRIMMER 20PF (EXCEPT AEP)
CT204 1-141-442-91 CAP, CERAMIC TRIMMER 20PF
< DIODE >
D201 8-719-801-78 DIODE 1SS184
D206 8-719-988-61 DIODE 1SS355TE-17
D220 8-719-988-61 DIODE 1SS355TE-17 (EXCEPT AEP)
< FERRITE BEAD >
FB202 1-469-152-11 FERRITE, EMI (SMD) (AEP)
< IC >
IC202 8-759-536-24 IC NJM-2296M-TE2
IC203 6-700-050-01 IC NJM2596M(TE2)
IC204 8-759-822-05 IC LA7213 (AEP)
IC205 8-759-822-05 IC LA7213 (AEP)
IC209 6-700-367-01 IC MB90089PF-G-238-BND
IC210 8-759-682-76 IC BA7622F-E2-A
< JACK >
J207 1-563-330-11 JACK (CTRL A1 II)
< CONNECTOR >
J208 1-779-801-11 CONNECTOR (ROUND TYPE) (VIDEO 1)
J209 1-779-801-11 CONNECTOR (ROUND TYPE) (VIDEO 2)
J210 1-779-801-11 CONNECTOR (ROUND TYPE) (TV/SAT,DVD/LD)
< S TERMINAL >
J211 1-779-800-11 TERMINAL, S (MONITOR)
< JUMPER RESISTOR >
JR200 1-216-296-11 SHORT CHIP 0
JR203 1-216-296-11 SHORT CHIP 0
JR204 1-216-296-11 SHORT CHIP 0
JR205 1-216-296-11 SHORT CHIP 0
JR206 1-216-296-11 SHORT CHIP 0
JR207 1-216-296-11 SHORT CHIP 0
JR208 1-216-296-11 SHORT CHIP 0
JR209 1-216-296-11 SHORT CHIP 0
JR210 1-216-296-11 SHORT CHIP 0
JR211 1-216-296-11 SHORT CHIP 0
JR212 1-216-296-11 SHORT CHIP 0
< JUMPER RESISTOR >
JW1 1-216-295-11 SHORT CHIP 0 (VA333ES)
JW2 1-216-295-11 SHORT CHIP 0 (VA333ES)
JW3 1-216-295-11 SHORT CHIP 0 (US,CND)
< COIL >
L201 1-216-296-11 SHORT CHIP 0 (EXCEPT AEP)
L201 1-500-425-11 FERRITE, EMI (SMD) (AEP)
L202 1-216-296-11 SHORT CHIP 0 (EXCEPT AEP)
L202 1-500-425-11 FERRITE, EMI (SMD) (AEP)
L203 1-216-296-11 SHORT CHIP 0 (EXCEPT AEP)
L203 1-500-425-11 FERRITE, EMI (SMD) (AEP)
L204 1-216-296-11 SHORT CHIP 0 (EXCEPT AEP)
L204 1-500-425-11 FERRITE, EMI (SMD) (AEP)
L205 1-408-781-00 INDUCTOR 22uH
< TRANSISTOR >
Q202 8-729-230-49 TRANSISTOR 2SC2712-YG
Q203 8-729-230-49 TRANSISTOR 2SC2712-YG
Q221 8-729-216-22 TRANSISTOR 2SA1162-G (EXCEPT AEP)
Q222 8-729-027-43 TRANSISTOR DTC114EKA-T146 (EXCEPT AEP)
Q223 8-729-230-49 TRANSISTOR 2SC2712-YG (EXCEPT AEP)
Q224 8-729-216-22 TRANSISTOR 2SA1162-G (EXCEPT AEP)
Q225 8-729-230-49 TRANSISTOR 2SC2712-YG (EXCEPT AEP)
< RESISTOR >
R212 1-216-022-00 METAL CHIP 75 5% 1/10W
R213 1-216-022-00 METAL CHIP 75 5% 1/10W
R214 1-216-022-00 METAL CHIP 75 5% 1/10W
R215 1-216-022-00 METAL CHIP 75 5% 1/10W
R216 1-216-022-00 METAL CHIP 75 5% 1/10W
R217 1-216-022-00 METAL CHIP 75 5% 1/10W
R218 1-216-022-00 METAL CHIP 75 5% 1/10W
R219 1-216-022-00 METAL CHIP 75 5% 1/10W
R220 1-216-022-00 METAL CHIP 75 5% 1/10W
R221 1-216-022-00 METAL CHIP 75 5% 1/10W
R222 1-216-022-00 METAL CHIP 75 5% 1/10W
R223 1-216-022-00 METAL CHIP 75 5% 1/10W
R224 1-216-022-00 METAL CHIP 75 5% 1/10W
R225 1-216-022-00 METAL CHIP 75 5% 1/10W
R226 1-216-097-11 RES-CHIP 100K 5% 1/10W
R227 1-216-097-11 RES-CHIP 100K 5% 1/10W
R228 1-216-097-11 RES-CHIP 100K 5% 1/10W
R229 1-216-097-11 RES-CHIP 100K 5% 1/10W
R230 1-216-097-11 RES-CHIP 100K 5% 1/10W
R231 1-216-001-00 METAL CHIP 10 5% 1/10W
R232 1-216-001-00 METAL CHIP 10 5% 1/10W
R233 1-216-001-00 METAL CHIP 10 5% 1/10W
R235 1-216-105-11 RES-CHIP 220K 5% 1/10W
(AEP)
R236 1-216-105-11 RES-CHIP 220K 5% 1/10W
(AEP)
R237 1-216-037-00 METAL CHIP 330 5% 1/10W
(AEP)
R238 1-216-037-00 METAL CHIP 330 5% 1/10W
(AEP)
R239 1-216-097-11 RES-CHIP 100K 5% 1/10W
R245 1-216-063-11 RES-CHIP 3.9K 5% 1/10W
R246 1-216-089-11 RES-CHIP 47K 5% 1/10W
R247 1-216-089-11 RES-CHIP 47K 5% 1/10W
R248 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R249 1-216-089-11 RES-CHIP 47K 5% 1/10W
R250 1-216-089-11 RES-CHIP 47K 5% 1/10W
R251 1-216-035-00 METAL CHIP 270 5% 1/10W
(EXCEPT AEP)
R252 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
S-VIDEO
