111
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R254 1-216-097-11 RES-CHIP 100K 5% 1/10W
R255 1-216-049-11 RES-CHIP 1K 5% 1/10W
R278 1-216-022-00 METAL CHIP 75 5% 1/10W
R279 1-216-022-00 METAL CHIP 75 5% 1/10W
R290 1-216-097-11 RES-CHIP 100K 5% 1/10W
R296 1-216-295-11 SHORT CHIP 0
R297 1-216-295-11 SHORT CHIP 0
R298 1-216-295-11 SHORT CHIP 0
R299 1-216-295-11 SHORT CHIP 0
R2220 1-249-393-11 CARBON 10 5% 1/4W
(TW,KR)
R2221 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT AEP)
R2222 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(EXCEPT AEP)
R2224 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(EXCEPT AEP)
R2225 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(EXCEPT AEP)
R2226 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT AEP)
R2227 1-216-073-00 RES-CHIP 10K 5% 1/10W
(EXCEPT AEP)
R2228 1-216-049-11 RES-CHIP 1K 5% 1/10W
(EXCEPT AEP)
R2229 1-216-049-11 RES-CHIP 1K 5% 1/10W
(EXCEPT AEP)
R2230 1-216-033-00 METAL CHIP 220 5% 1/10W
(EXCEPT AEP)
R2231 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(EXCEPT AEP)
R2232 1-216-295-11 SHORT CHIP 0 (EXCEPT AEP)
< RELAY >
RY220 1-515-622-11 RELAY (EXCEPT AEP)
< CONNECTOR >
TP201 1-784-921-11 PIN, CONNECTOR 4P
< VIBRATOR >
X202 1-781-821-21 VIBRATOR, CRYSTAL (14.3MHz) (EXCEPT AEP)
*************************************************************
A-4728-955-A UP CONVERT BOARD, COMPLETE
(DA4ES/DA7ES)
***************************
< CAPACITOR >
C3100 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(DA4ES/DA7ES)
C3101 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
(DA4ES/DA7ES)
C3102 1-126-947-11 ELECT 47uF 20% 10V
(DA4ES/DA7ES)
C3103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA4ES/DA7ES)
C3104 1-126-947-11 ELECT 47uF 20% 10V
(DA4ES/DA7ES)
C3105 1-104-665-11 ELECT 100uF 20% 10V
(DA4ES/DA7ES)
C3106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA4ES/DA7ES)
C3107 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3108 1-126-959-11 ELECT 0.47uF 20% 50V
(DA4ES/DA7ES)
C3109 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3110 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3111 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3112 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
(DA4ES/DA7ES)
C3113 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3114 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3115 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3116 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA4ES/DA7ES)
C3117 1-104-665-11 ELECT 100uF 20% 10V
(DA4ES/DA7ES)
C3118 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(DA4ES/DA7ES)
C3119 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
(DA4ES/DA7ES)
C3120 1-126-947-11 ELECT 47uF 20% 10V
(DA4ES/DA7ES)
C3121 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA4ES/DA7ES)
C3123 1-104-665-11 ELECT 100uF 20% 10V
(DA4ES/DA7ES)
C3124 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
(DA4ES/DA7ES)
C3125 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
(DA4ES/DA7ES)
C3126 1-130-495-00 MYLAR 0.1uF 5% 50V
(DA4ES/DA7ES)
C3127 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
(DA4ES/DA7ES)
C3128 1-126-961-11 ELECT 2.2uF 20% 50V
(DA4ES/DA7ES)
C3129 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3130 1-126-963-11 ELECT 4.7uF 20% 50V
(DA4ES/DA7ES)
C3131 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C3132 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
(DA4ES/DA7ES)
C3133 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
(DA4ES/DA7ES)
C3134 1-126-960-11 ELECT 1uF 20% 50V
(DA4ES/DA7ES)
C3135 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
(DA4ES/DA7ES)
C3136 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA4ES/DA7ES)
C3137 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DA4ES/DA7ES)
S-VIDEO UP CONVERT
