Sony STR-DA7ES - Up Convert Board Components

112
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C3138 1-126-947-11 ELECT 47uF 20% 10V
(DA4ES/DA7ES)
< CONNECTOR >
CN3101 1-766-724-11 CONNECTOR, BOARD TO BOARD 7P
(DA4ES/DA7ES)
< FERRITE BEAD >
FB3101 1-469-152-11 FERRITE, EMI (SMD) (DA4ES/DA7ES)
FB3102 1-469-152-11 FERRITE, EMI (SMD) (DA4ES/DA7ES)
FB3103 1-469-152-11 FERRITE, EMI (SMD) (DA4ES/DA7ES)
< IC >
IC3100 8-759-678-99 IC TC90A45F (DA4ES/DA7ES)
IC3101 8-759-826-19 IC MM1093NF (DA4ES/DA7ES)
< JUMPER RESISTOR >
JW3121 1-216-295-11 SHORT CHIP 0 (DA4ES/DA7ES)
JW3122 1-216-295-11 SHORT CHIP 0 (DA4ES/DA7ES)
JW3123 1-216-295-11 SHORT CHIP 0 (DA4ES/DA7ES)
< COIL >
L3100 1-412-064-11 INDUCTOR 100uH (DA4ES/DA7ES)
L3101 1-412-011-31 INDUCTOR 27uH (DA4ES/DA7ES)
L3102 1-412-064-11 INDUCTOR 100uH (DA4ES/DA7ES)
L3103 1-412-011-31 INDUCTOR 27uH (DA4ES/DA7ES)
L3104 1-412-011-31 INDUCTOR 27uH (DA4ES/DA7ES)
L3105 1-414-194-11 INDUCTOR 33uH (DA4ES/DA7ES)
< TRANSISTOR >
Q3100 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
Q3101 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
Q3102 8-729-216-22 TRANSISTOR 2SA1162-G (DA4ES/DA7ES)
Q3103 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
Q3104 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
Q3105 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
Q3106 8-729-216-22 TRANSISTOR 2SA1162-G (DA4ES/DA7ES)
Q3107 8-729-216-22 TRANSISTOR 2SA1162-G (DA4ES/DA7ES)
Q3108 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
Q3109 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
Q3110 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
Q3111 8-729-216-22 TRANSISTOR 2SA1162-G (DA4ES/DA7ES)
Q3112 8-729-216-22 TRANSISTOR 2SA1162-G (DA4ES/DA7ES)
< RESISTOR >
R3101 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(DA4ES/DA7ES)
R3102 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(DA4ES/DA7ES)
R3103 1-216-043-11 RES-CHIP 560 5% 1/10W
(DA4ES/DA7ES)
R3104 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(DA4ES/DA7ES)
R3105 1-216-047-11 RES-CHIP 820 5% 1/10W
(DA4ES/DA7ES)
R3106 1-216-047-11 RES-CHIP 820 5% 1/10W
(DA4ES/DA7ES)
R3107 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA4ES/DA7ES)
R3108 1-216-043-11 RES-CHIP 560 5% 1/10W
(DA4ES/DA7ES)
R3110 1-216-047-11 RES-CHIP 820 5% 1/10W
(DA4ES/DA7ES)
R3111 1-216-047-11 RES-CHIP 820 5% 1/10W
(DA4ES/DA7ES)
R3112 1-216-043-11 RES-CHIP 560 5% 1/10W
(DA4ES/DA7ES)
R3113 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(DA4ES/DA7ES)
R3114 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(DA4ES/DA7ES)
R3115 1-216-043-11 RES-CHIP 560 5% 1/10W
(DA4ES/DA7ES)
R3116 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(DA4ES/DA7ES)
R3117 1-216-047-11 RES-CHIP 820 5% 1/10W
(DA4ES/DA7ES)
R3118 1-216-025-11 RES-CHIP 100 5% 1/10W
(DA4ES/DA7ES)
R3120 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA4ES/DA7ES)
R3121 1-216-043-11 RES-CHIP 560 5% 1/10W
(DA4ES/DA7ES)
R3122 1-260-354-71 CARBON 150 5% 1/2W
(DA4ES/DA7ES)
R3123 1-216-047-11 RES-CHIP 820 5% 1/10W
(DA4ES/DA7ES)
R3124 1-216-043-11 RES-CHIP 560 5% 1/10W
(DA4ES/DA7ES)
R3125 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(DA4ES/DA7ES)
R3126 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
(DA4ES/DA7ES)
R3127 1-216-043-11 RES-CHIP 560 5% 1/10W
(DA4ES/DA7ES)
R3128 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
(DA4ES/DA7ES)
R3129 1-216-047-11 RES-CHIP 820 5% 1/10W
(DA4ES/DA7ES)
R3130 1-216-025-11 RES-CHIP 100 5% 1/10W
(DA4ES/DA7ES)
R3131 1-216-039-00 METAL CHIP 390 5% 1/10W
(DA4ES/DA7ES)
R3132 1-216-075-00 METAL CHIP 12K 5% 1/10W
(DA4ES/DA7ES)
R3133 1-216-043-11 RES-CHIP 560 5% 1/10W
(DA4ES/DA7ES)
R3134 1-260-354-71 CARBON 150 5% 1/2W
(DA4ES/DA7ES)
R3136 1-216-073-00 RES-CHIP 10K 5% 1/10W
(DA4ES/DA7ES)
R3137 1-216-073-00 RES-CHIP 10K 5% 1/10W
(DA4ES/DA7ES)
R3138 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
(DA4ES/DA7ES)
R3139 1-216-077-11 RES-CHIP 15K 5% 1/10W
(DA4ES/DA7ES)
R3140 1-216-121-11 RES-CHIP 1M 5% 1/10W
(DA4ES/DA7ES)
UP CONVERT
