113
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark
R3141 1-216-039-00 METAL CHIP 390 5% 1/10W
(DA4ES/DA7ES)
R3142 1-216-022-00 METAL CHIP 75 5% 1/10W
(DA4ES/DA7ES)
R3143 1-216-022-00 METAL CHIP 75 5% 1/10W
(DA4ES/DA7ES)
R3144 1-216-049-11 RES-CHIP 1K 5% 1/10W
(DA4ES/DA7ES)
R3145 1-216-045-00 METAL CHIP 680 5% 1/10W
(DA4ES/DA7ES)
R3146 1-216-035-00 METAL CHIP 270 5% 1/10W
(DA4ES/DA7ES)
< VIBRATOR >
X3100 1-781-342-21 OSCILLATOR, CRYSTAL (3.5795MHz)
(DA4ES/DA7ES)
*************************************************************
1-685-490-11 VIDEO3 BOARD
*************
< CAPACITOR >
C113 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C114 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C115 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C117 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< CONNECTOR >
* CNP107 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P
< JACK >
J102 1-764-190-21 JACK, PIN 3P (VIDEO 3 INPUT)
< JUMPER RESISTOR >
JR101 1-216-295-11 SHORT CHIP 0
< RESISTOR >
R168 1-216-022-00 METAL CHIP 75 5% 1/10W
R169 1-216-022-00 METAL CHIP 75 5% 1/10W
R170 1-216-022-00 METAL CHIP 75 5% 1/10W
R171 1-216-049-11 RES-CHIP 1K 5% 1/10W
R172 1-216-049-11 RES-CHIP 1K 5% 1/10W
R173 1-216-097-11 RES-CHIP 100K 5% 1/10W
R174 1-216-097-11 RES-CHIP 100K 5% 1/10W
*************************************************************
1-685-489-11 VOLUME BOARD
**************
< CONNECTOR >
CNP105 1-779-978-11 PIN, CONNECTOR 3P
< ROTARY ENCODER >
RV103 1-477-382-11 ENCODER, ROTARY (MASTER VOLUME)
*************************************************************
1-685-494-11 4/8 BOARD
*********
< CONNECTOR >
* CNP903 1-564-607-11 PIN, CONNECTOR (3.96mm PITCH) 6P
< SWITCH >
S902 1-771-876-11 SWITCH, POWER (IMPEDANCE SELECTOR)
*************************************************************
MISCELLANEOUS
***************
115 1-773-162-11 WIRE (FLAT TYPE) (21 CORE)
116 1-773-021-11 WIRE (FLAT TYPE) (15 CORE)
157 1-773-021-11 WIRE (FLAT TYPE) (15 CORE)
0 160 1-769-079-22 CORD, POWER (KR)
162 1-823-582-11 WIRE (FLAT TYPE) (15 CORE)
164 1-769-971-11 WIRE (FLAT TYPE) (13 CORE)
166 1-769-969-11 WIRE (FLAT TYPE) (13 CORE)
167 1-769-975-11 WIRE (FLAT TYPE) (13 CORE)
169 1-769-879-11 WIRE (FLAT TYPE) (7 CORE) (DA4ES/DA7ES)
201 1-769-971-11 WIRE (FLAT TYPE) (13 CORE)
256 1-469-241-11 CORE, FERRITE (RFC-8 BK)
0 F801 1-533-312-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(10A/125V)
0 F802 1-533-312-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(10A/125V)
0 F805 1-532-464-51 FUSE, TIME-LAG (T2.5AL/250V) (VA333ES)
0 F805 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(4A/125V) (DA4ES/DA7ES)
0 F806 1-532-464-51 FUSE, TIME-LAG (T2.5AL/250V) (VA333ES)
0 F806 1-533-419-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(4A/125V) (DA4ES/DA7ES)
0 F901 1-532-325-00 FUSE, TIME-LAG (T6.3AL/250V) (AEP,KR)
0 F901 1-576-379-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(15A/250V) (US,CND,TW)
0 F902 1-532-464-51 FUSE, TIME-LAG (T2.5AL/250V) (AEP)
IC502 8-749-014-72 IC SAP15N
IC503 8-749-014-73 IC SAP15P
IC552 8-749-014-72 IC SAP15N
IC553 8-749-014-73 IC SAP15P
IC602 8-749-014-72 IC SAP15N
IC603 8-749-014-73 IC SAP15P
IC652 8-749-014-72 IC SAP15N
IC653 8-749-014-73 IC SAP15P
IC654 8-749-014-72 IC SAP15N
IC655 8-749-014-73 IC SAP15P
IC702 8-749-014-72 IC SAP15N
IC703 8-749-014-73 IC SAP15P
IC752 8-749-014-72 IC SAP15N
IC753 8-749-014-73 IC SAP15P
0 T901 1-437-270-11 TRANSFORMER, POWER (US)
0 T901 1-437-271-11 TRANSFORMER, POWER (DA4ES:CND)
0 T901 1-437-272-11 TRANSFORMER, POWER (TW)
0 T901 1-437-274-11 TRANSFORMER, POWER (AEP,KR)
0 T901 1-437-872-11 TRANSFORMER, POWER (DA7ES:CND)
TU301 1-693-539-21 TUNER PACK (FM/AM) (DA4ES/DA7ES)
Ref. No. Part No. Description Remark
UP CONVERT 4/8VOLUMEVIDEO3
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
