4
STR-DA4ES/DA7ES/VA333ES
Frequency response
PHONO RIAA equalization curve
±0.5 dB
CD/SACD, TAPE, 10 Hz – 100 kHz
MD/DAT, TV/SAT, +0.5/–2 dB (with sound
DVD/LD, VIDEO 1, 2, field, equalizer, and bass
3 boost bypassed)
Inputs (Analog)
PHONO Sensitivity: 2.5 mV
Impedance: 50 kilohms
S/N
5)
: 86 dB (A, 2.5 mV
6)
)
MULTI CHANNEL Sensitivity: 150 mV
IN 1, 2, CD/SACD, Impedance: 50 kilohms
TAPE, MD/DAT, S/N
5)
: 100 dB
DVD/LD, TV/SAT, (A, 150 mV
6)
)
VIDEO 1, 2, 3
5) INPUT SHORT.
6) Weighted network, input level.
Inputs (Digital)
CD/SACD, DVD/LD Sensitivity: –
(Coaxial) Impedance: 75 ohms
S/N: 100 dB
(A, 20 kHz LPF)
CD/SACD, DVD/LD, Sensitivity: –
TV/SAT, Impedance: –
MD/DAT (Optical) S/N: 100 dB
(A, 20 kHz LPF)
Outputs
TAPE, MD/DAT Voltage: 150 mV
(REC OUT), VIDEO Impedance: 10 kilohms
1, 2 (AUDIO OUT)
FRONT L/R, Voltage: 2 V
CENTER, Impedance: 1 kilohms
SURROUND L/R,
SURROUND BACK L/R,
SUB WOOFER
EQ
BASS: 99 Hz~1.0 kHz
(21 steps)
MID (FRONT L/R, CENTER only):
198 Hz~10 kHz
(36 steps)
TREBLE: 1.0 kHz~10 kHz
(23 steps)
Gain levels: ±10 dB, 0.5 dB step
FM TUNER SECTION
Tuning range 87.5 – 108.0 MHz
Antenna terminals 75 ohms, unbalanced
Sensitivity
Mono: 18.3 dBf, 2.2 µV/75 ohms
Stereo: 38.3 dBf, 22.5 µV/75 ohms
Usable sensitivity 11.2 dBf, 1 µV/75 ohms
S/N
Mono: 76 dB
Stereo: 70 dB
Harmonic distortion at 1 kHz
Mono: 0.3%
Stereo: 0.5%
Separation 45 dB at 1 kHz
Frequency response 30 Hz – 15 kHz,
+0.5/–2 dB
Selectivity 60 dB at 400 kHz
AM TUNER SECTION
Tuning range 531 – 1602 kHz
Antenna Loop antenna
Usable sensitivity 50 dB/m (at 999 kHz)
S/N 54 dB (at 50 mV/m)
Harmonic distortion 0.5 % (50 mV/m,
400 Hz)
Selectivity 35 dB
VIDEO SECTION
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
S-video: Y: 1 Vp-p, 75 ohms
C: 0.286 Vp-p, 75 ohms
COMPONENT VIDEO: Y: 1 Vp-p, 75 ohms
B-Y: 0.7 Vp-p, 75 ohms
R-Y: 0.7 Vp-p, 75 ohms
