Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
102
STR-DA1000ES/DB790
J305 1-794-978-11 JACK, PIN 3P
(VIDEO VIDEO 2 OUT, DVD IN, TV/SAT IN)
< RESISTOR >
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
**************************************************************
VIDEO-AU BOARD
***************
< CAPACITOR >
C201 1-127-868-11 CERAMIC 2200PF 10% 50V
C211 1-127-880-11 CERAMIC 0.022uF 10% 50V
C212 1-127-880-11 CERAMIC 0.022uF 10% 50V
C213 1-128-809-11 CERAMIC 100PF 5% 50V
C214 1-127-876-11 CERAMIC 0.01uF 10% 50V
C215 1-127-868-11 CERAMIC 2200PF 10% 50V
< CONNECTOR >
CN201 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
* CN202 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< IC >
IC201 8-759-582-65 IC TC9273N-014
< JACK >
J201 1-774-411-11 JACK, PIN 6P (VIDEO AUDIO
VIDEO 2 OUT, DVD IN, TV/SAT IN)
J202 1-774-411-11 JACK, PIN 6P (VIDEO AUDIO
VIDEO 1 IN, VIDEO 1 OUT, VIDEO 2 IN)
< RESISTOR >
R201 1-249-417-11 CARBON 1K 5% 1/4W
R202 1-249-417-11 CARBON 1K 5% 1/4W
R203 1-249-421-11 CARBON 2.2K 5% 1/4W
R204 1-249-417-11 CARBON 1K 5% 1/4W
R205 1-249-421-11 CARBON 2.2K 5% 1/4W
R206 1-249-417-11 CARBON 1K 5% 1/4W
0R207 1-249-399-11 CARBON 33 5% 1/4W F
0R208 1-249-399-11 CARBON 33 5% 1/4W F
R211 1-249-417-11 CARBON 1K 5% 1/4W
R251 1-249-417-11 CARBON 1K 5% 1/4W
R252 1-249-417-11 CARBON 1K 5% 1/4W
R253 1-249-421-11 CARBON 2.2K 5% 1/4W
R254 1-249-417-11 CARBON 1K 5% 1/4W
R255 1-249-421-11 CARBON 2.2K 5% 1/4W
R256 1-249-417-11 CARBON 1K 5% 1/4W
**************************************************************
VIDEO VIDEO-AU VOL
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
VOL BOARD
**********
< CONNECTOR >
CN1060 1-779-978-11 PIN, CONNECTOR 3P
< ROTARY ENCODER >
RV1060 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
**************************************************************
MISCELLANEOUS
**************
053 1-696-847-21 CORD, POWER (AUS)
053 1-769-079-22 CORD, POWER (KR)
053 1-769-743-11 CORD, POWER (CND)
053 1-777-071-23 CORD, POWER (AEP, UK, SP, MY)
053 1-782-464-22 CORD, POWER (CH)
053 1-783-820-11 CORD, POWER (US)
053 1-827-597-41 CORD, POWER (TW)
108 1-769-938-11 WIRE (FLAT TYPE) (11 CORE)
(DA1000ES/DB790: SP, MY, TW, KR, AUS, CH)
108 1-773-002-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK)
354 1-773-270-11 WIRE (FLAT TYPE) (27 CORE)
F1 1-532-504-51 FUSE (4A/250V)
(DB790: AEP, UK, SP, MY, KR, AUS, CH)
F1 1-533-312-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(10A/125V) (DA1000ES/DB790: TW)
F2 1-532-464-51 FUSE (T2.5AL/250V) (DB790: SP, MY)
F2 1-533-312-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(10A/125V) (DA1000ES)
F903 1-532-504-51 FUSE (4A/250V) (DB790)
F903 1-576-108-11 FUSE (4A/125V) (DA1000ES)
F904 1-532-504-51 FUSE (4A/250V) (DB790)
F904 1-576-108-11 FUSE (4A/125V) (DA1000ES)
IC952 8-759-231-53 IC M5F7805L
IC953 8-759-231-53 IC M5F7805L
IC954 8-759-245-87 IC M5F7915L
IC955 8-759-231-59 IC M5F7815L
Q402 6-702-390-01 IC MN2488-OPY-MK
Q403 6-702-391-01 IC MP1620-OPY-MK
Q452 6-702-390-01 IC MN2488-OPY-MK
Q453 6-702-391-01 IC MP1620-OPY-MK
Q502 6-702-390-01 IC MN2488-OPY-MK
Q503 6-702-391-01 IC MP1620-OPY-MK
Q552 6-702-390-01 IC MN2488-OPY-MK
Q553 6-702-391-01 IC MP1620-OPY-MK
Q602 6-702-390-01 IC MN2488-OPY-MK
Q603 6-702-391-01 IC MP1620-OPY-MK
Q652 6-702-390-01 IC MN2488-OPY-MK
Q653 6-702-391-01 IC MP1620-OPY-MK
Q702 6-702-390-01 IC MN2488-OPY-MK
Q703 6-702-391-01 IC MP1620-OPY-MK
0T901 1-439-800-11 TRANSFORMER, POWER (DB790: CH)
0T901 1-439-801-11 TRANSFORMER, POWER (DB790: TW)
0T901 1-439-802-11 TRANSFORMER, POWER (DA1000ES)
0T901 1-439-803-11 TRANSFORMER, POWER
(DB790: AEP, UK, SP, MY, KR, AUS)
