Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
101
STR-DA1000ES/DB790
C749 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB790)
< CONNECTOR >
CN443 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
CN444 1-770-726-11 CONNECTOR, BOARD TO BOARD 6P
CN451 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D649 8-719-991-33 DIODE 1SS133T-77 (DA1000ES)
D699 8-719-991-33 DIODE 1SS133T-77
< JACK >
J203 1-770-377-31 JACK, PIN 1P (SUB WOOFER)
< COIL >
L649 1-420-872-52 COIL, AIR-CORE (DA1000ES)
L699 1-420-872-52 COIL, AIR-CORE
L749 1-420-872-52 COIL, AIR-CORE
< RESISTOR >
R209 1-249-417-11 CARBON 1K 5% 1/4W
0R648 1-249-393-11 CARBON 10 5% 1/4W F
(DA1000ES)
0R649 1-249-393-11 CARBON 10 5% 1/4W F
(DA1000ES)
0R697 1-249-393-11 CARBON 10 5% 1/4W F
0R698 1-249-393-11 CARBON 10 5% 1/4W F
(DB790)
0R699 1-249-393-11 CARBON 10 5% 1/4W F
0R748 1-249-393-11 CARBON 10 5% 1/4W F
(DB790)
0R749 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY649 1-515-920-11 RELAY (24V) (DA1000ES)
RY699 1-515-920-11 RELAY (24V)
< TERMINAL >
TM444 1-694-933-21 TERMINAL BOARD (SP) (4P) (SPEAKERS
CENTER, SURROUND BACK) (DB790)
TM444 1-780-038-11 TERMINAL BOARD (SP) (6P) (SPEAKERS
CENTER, SURR BACK) (DA1000ES)
**************************************************************
1-689-177-11 STAY BOARD (DB790)
***********
< CONNECTOR >
CN2704 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
**************************************************************
1-689-747-11 STAY2 BOARD (DB790)
***********
< CONNECTOR >
CN2705 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
**************************************************************
1-689-748-11 STAY3 BOARD
************
< CONNECTOR >
CN2706 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
CN2707 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
**************************************************************
1-689-784-11 STAY4 BOARD
************
< CONNECTOR >
CN452 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
CN453 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
**************************************************************
TH BOARD
*********
< CONNECTOR >
CN911 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< THERMISTOR >
THP901 1-817-728-11 SENSOR, THERMISTOR
**************************************************************
1-688-645-11 VIDEO BOARD
************
< CAPACITOR >
C301 1-128-805-11 CERAMIC 47PF 5% 50V
C302 1-127-868-11 CERAMIC 2200PF 10% 50V
C303 1-126-964-11 ELECT 10uF 20% 50V
C304 1-127-868-11 CERAMIC 2200PF 10% 50V
C305 1-128-805-11 CERAMIC 47PF 5% 50V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-128-805-11 CERAMIC 47PF 5% 50V
C308 1-127-868-11 CERAMIC 2200PF 10% 50V
C309 1-126-964-11 ELECT 10uF 20% 50V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-127-888-11 CERAMIC 0.1uF 10% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C315 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CN301 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
< IC >
IC301 6-701-890-01 IC NJM2595D
< JACK >
J302 1-794-970-11 JACK, PIN 1P (VIDEO MONITOR OUT)
J304 1-794-978-11 JACK, PIN 3P
(VIDEO VIDEO 1 IN, VIDEO 1 OUT, VIDEO 2 IN)
SP-B STAY STAY2 STAY3 STAY4 TH VIDEO
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Ver 1.3
