Page #100 background imageLoading...
Page #100 background image
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
100
STR-DA1000ES/DB790
1-689-176-11 SEC3 BOARD
***********
< CONNECTOR >
CN57 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN58 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
**************************************************************
1-688-636-11 SP-A BOARD
***********
< CAPACITOR >
C443 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB790)
C444 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C444 1-128-817-11 CERAMIC 470PF 5% 50V
(DB790)
C448 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C448 1-128-817-11 CERAMIC 470PF 5% 50V
(DB790)
C449 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB790)
C493 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB790)
C498 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C498 1-128-817-11 CERAMIC 470PF 5% 50V
(DB790)
C499 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB790)
C548 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C548 1-128-817-11 CERAMIC 470PF 5% 50V
(DB790)
C549 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB790)
C598 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C598 1-128-817-11 CERAMIC 470PF 5% 50V
(DB790)
C599 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB790)
C698 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C698 1-128-817-11 CERAMIC 470PF 5% 50V
(DB790)
< CONNECTOR >
CN447 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
CN448 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
* CN449 1-770-727-11 CONNECTOR, BOARD TO BOARD 8P
CN450 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D444 8-719-991-33 DIODE 1SS133T-77
D449 8-719-991-33 DIODE 1SS133T-77
D549 8-719-991-33 DIODE 1SS133T-77
< COIL >
L449 1-420-872-52 COIL, AIR-CORE
L499 1-420-872-52 COIL, AIR-CORE
L549 1-420-872-52 COIL, AIR-CORE
L599 1-420-872-52 COIL, AIR-CORE
< RESISTOR >
0R443 1-249-393-11 CARBON 10 5% 1/4W F
(DB790)
0R444 1-249-393-11 CARBON 10 5% 1/4W F
0R447 1-249-393-11 CARBON 10 5% 1/4W F
0R448 1-249-393-11 CARBON 10 5% 1/4W F
(DB790)
0R449 1-249-393-11 CARBON 10 5% 1/4W F
0R493 1-249-393-11 CARBON 10 5% 1/4W F
(DB790)
0R498 1-249-393-11 CARBON 10 5% 1/4W F
(DB790)
0R499 1-249-393-11 CARBON 10 5% 1/4W F
0R547 1-249-393-11 CARBON 10 5% 1/4W F
0R548 1-249-393-11 CARBON 10 5% 1/4W F
(DB790)
0R549 1-249-393-11 CARBON 10 5% 1/4W F
0R598 1-249-393-11 CARBON 10 5% 1/4W F
(DB790)
0R599 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY444 1-515-920-11 RELAY (24V)
RY449 1-515-920-11 RELAY (24V)
RY549 1-515-920-11 RELAY (24V)
< TERMINAL >
TM449 1-780-033-11 TERMINAL BOARD (SP) (8P)
(SPEAKERS FRONT B, SURR) (DA1000ES)
TM449 1-780-033-21 TERMINAL BOARD (SP) (8P)
(SPEAKERS FRONT B, SURR) (DB790)
TM699 1-694-933-12 TERMINAL BOARD (SP) (4P)
(SPEAKERS FRONT A) (DA1000ES)
TM699 1-694-933-21 TERMINAL BOARD (SP) (4P)
(SPEAKERS FRONT A) (DB790)
**************************************************************
1-688-637-11 SP-B BOARD
***********
< CAPACITOR >
C210 1-127-868-11 CERAMIC 2200PF 10% 50V
C494 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C494 1-128-817-11 CERAMIC 470PF 5% 50V
(DB790)
C648 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C699 1-127-872-11 CERAMIC 4700PF 10% 50V
(DB790)
C748 1-128-809-11 CERAMIC 100PF 5% 50V
(DA1000ES)
C748 1-128-817-11 CERAMIC 470PF 5% 50V
(DB790)
SEC3 SP-A SP-B
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
