Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
99
STR-DA1000ES/DB790
IC852 8-759-822-05 IC LA7213 (DA1000ES)
< JACK >
J850 1-794-937-11 CONNECTOR (DIN) 2P
(VIDEO S-VIDEO DVD IN, TV/SAT IN)
J851 1-537-943-11 CONNECTOR (DIN) 1P
(VIDEO S-VIDEO MONITOR OUT)
J852 1-794-937-11 CONNECTOR (DIN) 2P
(VIDEO S-VIDEO VIDEO 1 IN/OUT)
< TRANSISTOR >
Q850 8-729-030-02 TRANSISTOR DTC144ESA (DA1000ES)
Q851 8-729-201-53 TRANSISTOR 2SA1015TP-YGR
(DA1000ES)
< RESISTOR >
R854 1-247-804-11 CARBON 75 5% 1/4W
R855 1-247-804-11 CARBON 75 5% 1/4W
R856 1-247-804-11 CARBON 75 5% 1/4W
R857 1-247-804-11 CARBON 75 5% 1/4W
R858 1-247-804-11 CARBON 75 5% 1/4W
R859 1-247-804-11 CARBON 75 5% 1/4W
R860 1-247-804-11 CARBON 75 5% 1/4W
R861 1-247-804-11 CARBON 75 5% 1/4W
R862 1-247-804-11 CARBON 75 5% 1/4W
R863 1-247-804-11 CARBON 75 5% 1/4W
R864 1-247-883-00 CARBON 150K 5% 1/4W
(DA1000ES)
R865 1-249-411-11 CARBON 330 5% 1/4W
(DA1000ES)
R866 1-249-421-11 CARBON 2.2K 5% 1/4W
(DA1000ES)
R867 1-249-429-11 CARBON 10K 5% 1/4W
(DA1000ES)
< RELAY >
RY850 1-755-359-11 RELAY (DA1000ES)
**************************************************************
A-4733-518-A SBL BOARD, COMPLETE (DA1000ES)
********************
< CAPACITOR >
C731 1-126-947-11 ELECT 47uF 20% 35V
C732 1-128-813-11 CERAMIC 220PF 5% 50V
C2701 1-137-505-11 FILM 220PF 5% 100V
C2702 1-128-551-11 ELECT 22uF 20% 63V
C2704 1-126-934-11 ELECT 220uF 20% 16V
C2705 1-126-940-11 ELECT 330uF 20% 25V
C2706 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2707 1-102-233-00 CERAMIC 33PF 10% 500V
C2708 1-137-383-11 MYLAR 220PF 5% 100V
C2807 1-128-582-11 ELECT 10uF 20% 100V
C2808 1-128-582-11 ELECT 10uF 20% 100V
< CONNECTOR >
CN732 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
CN2701 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
CN2703 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D2701 8-719-109-89 DIODE RD5.6ESB2
< TRANSISTOR >
Q731 8-729-044-08 TRANSISTOR 2SD1915 (F) -T (TA).SO
Q733 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q2701 8-729-045-15 TRANSISTOR 2SC5169-FG
Q2703 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q2704 8-729-199-22 TRANSISTOR 2SA992-FA
Q2705 8-729-021-74 TRANSISTOR 2SA949-OY
Q2706 8-729-021-73 TRANSISTOR 2SC2229-OY
< RESISTOR >
0R712 1-249-405-11 CARBON 100 5% 1/4W F
0R713 1-249-405-11 CARBON 100 5% 1/4W F
0R714 1-234-182-11 ENCAPSULATED COMPONENT 0.22 5W F
R731 1-249-414-11 CARBON 560 5% 1/4W
R732 1-249-422-11 CARBON 2.7K 5% 1/4W
0R735 1-240-855-11 CARBON 6.2K 5% 1/4W F
R736 1-249-425-11 CARBON 4.7K 5% 1/4W
R737 1-249-420-11 CARBON 1.8K 5% 1/4W
R2701 1-249-417-11 CARBON 1K 5% 1/4W
R2702 1-249-438-11 CARBON 56K 5% 1/4W
R2703 1-249-411-11 CARBON 330 5% 1/4W
R2704 1-249-418-11 CARBON 1.2K 5% 1/4W
R2705 1-249-425-11 CARBON 4.7K 5% 1/4W
R2706 1-249-418-11 CARBON 1.2K 5% 1/4W
R2707 1-249-414-11 CARBON 560 5% 1/4W
R2708 1-247-843-11 CARBON 3.3K 5% 1/4W
R2709 1-249-560-31 CARBON 2.2K 5% 1/4W
R2710 1-249-594-31 CARBON 56K 5% 1/4W
R2711 1-249-441-11 CARBON 100K 5% 1/4W
R2712 1-249-441-11 CARBON 100K 5% 1/4W
0R2713 1-249-413-11 CARBON 470 5% 1/4W F
0R2714 1-249-406-11 CARBON 120 5% 1/4W F
0R2715 1-249-406-11 CARBON 120 5% 1/4W F
R2716 1-249-435-11 CARBON 33K 5% 1/4W
0R2717 1-249-393-11 CARBON 10 5% 1/4W F
0R2718 1-249-393-11 CARBON 10 5% 1/4W F
R2719 1-249-407-11 CARBON 150 5% 1/4W
< VARIABLE RESISTOR >
RV731 1-238-597-11 RES, ADJ, CARBON 1K
**************************************************************
1-689-174-11 SEC1 BOARD
***********
< CONNECTOR >
CN52 1-785-103-11 PIN, CONNECTOR (3.96mm PITCH) 5P
CN53 1-691-765-31 PLUG (MICRO CONNECTOR) 3P
**************************************************************
S-VIDEO SBL SEC1
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
