Sony STR-DB790 - Page 98

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
98
STR-DA1000ES/DB790
R702 1-249-417-11 CARBON 1K 5% 1/4W
R703 1-249-441-11 CARBON 100K 5% 1/4W
R715 1-249-437-11 CARBON 47K 5% 1/4W
(DA1000ES)
R716 1-249-441-11 CARBON 100K 5% 1/4W
(DA1000ES)
0R719 1-249-393-11 CARBON 10 5% 1/4W F
(DA1000ES)
R738 1-249-439-11 CARBON 68K 5% 1/4W
(DA1000ES)
R739 1-249-431-11 CARBON 15K 5% 1/4W
(DA1000ES)
R743 1-249-437-11 CARBON 47K 5% 1/4W
(DA1000ES)
R751 1-249-427-11 CARBON 6.8K 5% 1/4W
R752 1-249-417-11 CARBON 1K 5% 1/4W
R753 1-249-441-11 CARBON 100K 5% 1/4W
R782 1-249-441-11 CARBON 100K 5% 1/4W
R802 1-249-417-11 CARBON 1K 5% 1/4W
R805 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-249-433-11 CARBON 22K 5% 1/4W
R807 1-249-429-11 CARBON 10K 5% 1/4W
R812 1-249-421-11 CARBON 2.2K 5% 1/4W
R813 1-249-421-11 CARBON 2.2K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W
R815 1-249-429-11 CARBON 10K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-429-11 CARBON 10K 5% 1/4W
R818 1-249-429-11 CARBON 10K 5% 1/4W
R820 1-249-421-11 CARBON 2.2K 5% 1/4W
R821 1-249-429-11 CARBON 10K 5% 1/4W
0R824 1-215-867-00 METAL OXIDE 470 5% 1W F
0R825 1-215-867-00 METAL OXIDE 470 5% 1W F
R826 1-247-903-00 CARBON 1M 5% 1/4W
R827 1-249-417-11 CARBON 1K 5% 1/4W
R828 1-249-425-11 CARBON 4.7K 5% 1/4W
0R829 1-249-393-11 CARBON 10 5% 1/4W F
R833 1-247-903-00 CARBON 1M 5% 1/4W
R838 1-249-421-11 CARBON 2.2K 5% 1/4W
R839 1-249-429-11 CARBON 10K 5% 1/4W
0R841 1-249-399-11 CARBON 33 5% 1/4W F
0R846 1-249-399-11 CARBON 33 5% 1/4W F
R847 1-249-421-11 CARBON 2.2K 5% 1/4W
R848 1-249-429-11 CARBON 10K 5% 1/4W
0R849 1-249-393-11 CARBON 10 5% 1/4W F
R850 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-427-11 CARBON 6.8K 5% 1/4W
R852 1-249-433-11 CARBON 22K 5% 1/4W
R853 1-249-433-11 CARBON 22K 5% 1/4W
< VARIABLE RESISTOR >
RV431 1-238-597-11 RES, ADJ, CARBON 1K
RV481 1-238-597-11 RES, ADJ, CARBON 1K
RV531 1-238-597-11 RES, ADJ, CARBON 1K
RV581 1-238-597-11 RES, ADJ, CARBON 1K
RV631 1-238-597-11 RES, ADJ, CARBON 1K
RV681 1-238-597-11 RES, ADJ, CARBON 1K
< RELAY >
RY806 1-515-920-11 RELAY (24V)
RY807 1-755-483-11 RELAY
**************************************************************
1-689-173-11 PRI BOARD
**********
< CONNECTOR >
* CN3 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
**************************************************************
A-4733-530-A S-VIDEO BOARD, COMPLETE (DA1000ES)
A-4733-550-A S-VIDEO BOARD, COMPLETE (DB790)
************************
< CAPACITOR >
C850 1-128-805-11 CERAMIC 47PF 5% 50V
C851 1-128-805-11 CERAMIC 47PF 5% 50V
C852 1-128-805-11 CERAMIC 47PF 5% 50V
C853 1-128-805-11 CERAMIC 47PF 5% 50V
C854 1-128-825-11 CERAMIC 2200PF 5% 50V
C855 1-136-165-00 MYLAR 0.1uF 5% 50V
C856 1-136-165-00 MYLAR 0.1uF 5% 50V
C857 1-136-165-00 MYLAR 0.1uF 5% 50V
C858 1-126-964-11 ELECT 10uF 20% 50V
C859 1-126-964-11 ELECT 10uF 20% 50V
C860 1-126-964-11 ELECT 10uF 20% 50V
C861 1-128-825-11 CERAMIC 2200PF 5% 50V
C862 1-128-825-11 CERAMIC 2200PF 5% 50V
C863 1-127-888-11 CERAMIC 0.1uF 10% 50V
C864 1-136-165-00 MYLAR 0.1uF 5% 50V
C867 1-127-888-11 CERAMIC 0.1uF 10% 50V
C869 1-127-888-11 CERAMIC 0.1uF 10% 50V
C870 1-126-964-11 ELECT 10uF 20% 50V
C872 1-127-888-11 CERAMIC 0.1uF 10% 50V
C877 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DA1000ES)
C878 1-126-916-11 ELECT 1000uF 20% 6.3V
(DA1000ES)
C879 1-126-960-11 ELECT 1uF 20% 50V
(DA1000ES)
C890 1-104-665-11 ELECT 100uF 20% 25V
(DA1000ES)
< CONNECTOR >
CN851 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
* CN853 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN854 1-573-825-11 CONNECTOR, BOARD TO BOARD 11P
< DIODE >
D850 8-719-991-33 DIODE 1SS133T-77
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-991-33 DIODE 1SS133T-77 (DA1000ES)
D853 8-719-991-33 DIODE 1SS133T-77 (DA1000ES)
< IC >
IC850 6-701-890-01 IC NJM2595D
IC851 6-701-890-01 IC NJM2595D
MAIN PRI S-VIDEO
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
