Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
82
STR-DA1000ES/DB790
A-CLASS AC AU-IN
0R2414 1-249-406-11 CARBON 120 5% 1/4W F
0R2415 1-249-406-11 CARBON 120 5% 1/4W F
R2416 1-249-435-11 CARBON 33K 5% 1/4W
R2419 1-249-407-11 CARBON 150 5% 1/4W
R2501 1-249-417-11 CARBON 1K 5% 1/4W
R2502 1-249-438-11 CARBON 56K 5% 1/4W
R2503 1-249-411-11 CARBON 330 5% 1/4W
R2504 1-249-418-11 CARBON 1.2K 5% 1/4W
R2505 1-249-425-11 CARBON 4.7K 5% 1/4W
R2506 1-249-418-11 CARBON 1.2K 5% 1/4W
R2507 1-249-414-11 CARBON 560 5% 1/4W
R2508 1-247-843-11 CARBON 3.3K 5% 1/4W
R2509 1-249-560-31 CARBON 2.2K 5% 1/4W
R2510 1-249-594-31 CARBON 56K 5% 1/4W
R2511 1-249-441-11 CARBON 100K 5% 1/4W
R2512 1-249-441-11 CARBON 100K 5% 1/4W
0R2513 1-249-413-11 CARBON 470 5% 1/4W F
0R2514 1-249-406-11 CARBON 120 5% 1/4W F
0R2515 1-249-406-11 CARBON 120 5% 1/4W F
R2516 1-249-435-11 CARBON 33K 5% 1/4W
R2519 1-249-407-11 CARBON 150 5% 1/4W
0R2601 1-215-873-81 METAL OXIDE 4.7K 5% 1W F
0R2602 1-260-107-11 CARBON 4.7K 5% 1/2W F
0R2603 1-249-381-11 CARBON 1 5% 1/4W F
0R2604 1-249-381-11 CARBON 1 5% 1/4W F
R2605 1-249-413-11 CARBON 470 5% 1/4W
R2606 1-249-413-11 CARBON 470 5% 1/4W
R2607 1-247-883-00 CARBON 150K 5% 1/4W
R2610 1-249-429-11 CARBON 10K 5% 1/4W
**************************************************************
1-688-632-11 AC BOARD
*********
< CAPACITOR >
0C3 1-117-703-11 CERAMIC 0.0047uF 99% 250V
(DB790)
C52 1-136-287-11 FILM 0.0047uF 5% 100V
C53 1-137-465-11 MYLAR 0.056uF 5% 100V
C54 1-126-768-11 ELECT 2200uF 20% 16V
C55 1-126-960-11 ELECT 1uF 20% 50V
C56 1-128-817-11 CERAMIC 470PF 5% 50V
< CONNECTOR >
* CN1 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
CN2 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN51 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
< JACK >
0CNJ1 1-785-285-11 OUTLET, AC (1P) (AC OUTLET)
(DB790: SP, MY)
0CNJ1 1-785-834-11 OUTLET (1P) (AC OUTLET)
(DA1000ES/DB790: TW)
< DIODE >
D51 8-719-991-33 DIODE 1SS133T-77
D52 8-719-991-33 DIODE 1SS133T-77
D53 8-719-991-33 DIODE 1SS133T-77
D54 8-719-210-21 DIODE 11EQS04
D55 8-719-210-21 DIODE 11EQS04
D56 8-719-210-21 DIODE 11EQS04
D57 8-719-210-21 DIODE 11EQS04
< TRANSISTOR >
Q51 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q52 8-729-201-53 TRANSISTOR 2SA1015-GR
Q53 8-729-116-02 TRANSISTOR BA1A4M-TP
Q54 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q55 8-729-116-02 TRANSISTOR BA1A4M-TP
< RESISTOR >
0R1 1-219-237-11 SOLID 3.3M 20% 1/2W
(DA1000ES)
R51 1-249-421-11 CARBON 2.2K 5% 1/4W
R52 1-249-429-11 CARBON 10K 5% 1/4W
R53 1-249-415-11 CARBON 680 5% 1/4W
R54 1-249-437-11 CARBON 47K 5% 1/4W
R55 1-249-435-11 CARBON 33K 5% 1/4W
R56 1-249-429-11 CARBON 10K 5% 1/4W
R57 1-249-429-11 CARBON 10K 5% 1/4W
R59 1-249-441-11 CARBON 100K 5% 1/4W
R60 1-249-429-11 CARBON 10K 5% 1/4W
R61 1-249-435-11 CARBON 33K 5% 1/4W
< RELAY >
0RY1 1-755-298-11 RELAY
< TRANSFORMER >
0T2 1-435-281-11 TRANSFORMER, POWER (DA1000ES)
0T2 1-435-282-11 TRANSFORMER, POWER
(DB790: AEP, UK, SP, MY, KR, AUS, CH)
0T2 1-435-563-11 TRANSFORMER, POWER (DB790: TW)
**************************************************************
A-4733-528-A AU-IN BOARD, COMPLETE (DA1000ES)
A-4733-548-A AU-IN BOARD, COMPLETE
(DB790: SP, MY, TW, KR, CH)
A-4733-570-A AU-IN BOARD, COMPLETE
(DB790: AEP, UK, AUS)
*********************
< CAPACITOR >
C107 1-128-825-11 CERAMIC 2200PF 5% 50V
C110 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C110 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C110 1-135-681-11 ELECT 100uF 25V
(DB790: AEP, UK, AUS)
C111 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C111 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C111 1-135-681-11 ELECT 100uF 25V
(DB790: AEP, UK, AUS)
C112 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C112 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
