Page #83 background imageLoading...
Page #83 background image
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
83
STR-DA1000ES/DB790
AU-IN
C112 1-135-681-11 ELECT 100uF 25V
(DB790: AEP, UK, AUS)
C113 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C113 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C113 1-135-681-11 ELECT 100uF 25V
(DB790: AEP, UK, AUS)
C114 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C114 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C114 1-135-681-11 ELECT 100uF 25V
(DB790: AEP, UK, AUS)
C115 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C115 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C115 1-135-681-11 ELECT 100uF 25V
(DB790: AEP, UK, AUS)
C120 1-127-876-11 CERAMIC 0.01uF 10% 50V
C121 1-127-880-11 CERAMIC 0.022uF 10% 50V
C122 1-127-880-11 CERAMIC 0.022uF 10% 50V
C123 1-128-809-11 CERAMIC 100PF 5% 50V
C131 1-128-809-11 CERAMIC 100PF 5% 50V
(DB790)
C132 1-128-809-11 CERAMIC 100PF 5% 50V
(DB790)
C133 1-128-813-11 CERAMIC 220PF 5% 50V
(DB790)
C134 1-128-813-11 CERAMIC 220PF 5% 50V
(DB790)
C135 1-119-821-11 ELECT 2.2uF 20% 50V
(DB790)
C135 1-126-961-11 ELECT 2.2uF 20% 50V
(DA1000ES)
C136 1-119-821-11 ELECT 2.2uF 20% 50V
(DB790)
C136 1-126-961-11 ELECT 2.2uF 20% 50V
(DA1000ES)
C137 1-128-809-11 CERAMIC 100PF 5% 50V
C138 1-128-809-11 CERAMIC 100PF 5% 50V
C139 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C139 1-128-832-11 ELECT 220uF 20% 10V
(DB790)
C140 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C140 1-128-832-11 ELECT 220uF 20% 10V
(DB790)
C141 1-125-896-11 MYLAR 0.0091uF 5% 50V
C142 1-125-896-11 MYLAR 0.0091uF 5% 50V
C143 1-136-159-00 MYLAR 0.033uF 5% 50V
C144 1-136-159-00 MYLAR 0.033uF 5% 50V
C145 1-119-821-11 ELECT 2.2uF 20% 50V
(DB790)
C145 1-126-961-11 ELECT 2.2uF 20% 50V
(DA1000ES)
C146 1-119-821-11 ELECT 2.2uF 20% 50V
(DB790)
C146 1-126-961-11 ELECT 2.2uF 20% 50V
(DA1000ES)
C171 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C171 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C171 1-135-681-11 ELECT 100uF 25V
(DB790: AEP, UK, AUS)
C174 1-127-876-11 CERAMIC 0.01uF 10% 50V
C175 1-128-809-11 CERAMIC 100PF 5% 50V
C181 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C181 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C181 1-135-681-11 ELECT 100uF 25V
(DB790: AEP, UK, AUS)
< CONNECTOR >
CN102 1-764-867-41 CONNECTOR, BOARD TO BOARD 20P
CN103 1-764-867-41 CONNECTOR, BOARD TO BOARD 20P
CN104 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< IC >
IC101 6-703-975-01 IC TC9274N-017
IC110 8-759-167-88 IC NJM4565D
IC111 8-759-167-88 IC NJM4565D
IC112 8-759-167-88 IC NJM4565D
IC131 8-759-636-74 IC M5218AP-22
IC171 8-759-167-88 IC NJM4565D
IC172 8-759-167-88 IC NJM4565D
IC173 8-759-590-10 IC TC9273F-012 (EL)
< JACK >
J101 1-793-345-11 JACK, PIN 6P (ANALOG MULTI CH IN
FRONT, SURR, CENTER, SUB WOOFER)
J131 1-695-188-31 JACK, PIN 4P
(ANALOG MD/TAPE OUT, CD/SACD IN)
J151 1-695-188-31 JACK, PIN 4P
(ANALOG PHONO IN, MD/TAPE IN)
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W
R102 1-249-417-11 CARBON 1K 5% 1/4W
R103 1-249-417-11 CARBON 1K 5% 1/4W
R104 1-249-417-11 CARBON 1K 5% 1/4W
R105 1-249-417-11 CARBON 1K 5% 1/4W
R106 1-249-417-11 CARBON 1K 5% 1/4W
R110 1-249-437-11 CARBON 47K 5% 1/4W
R111 1-249-437-11 CARBON 47K 5% 1/4W
R112 1-249-437-11 CARBON 47K 5% 1/4W
R113 1-249-437-11 CARBON 47K 5% 1/4W
R114 1-249-437-11 CARBON 47K 5% 1/4W
R115 1-249-437-11 CARBON 47K 5% 1/4W
R119 1-249-417-11 CARBON 1K 5% 1/4W
R131 1-249-421-11 CARBON 2.2K 5% 1/4W
(DB790)
R132 1-249-421-11 CARBON 2.2K 5% 1/4W
(DB790)
R133 1-249-441-11 CARBON 100K 5% 1/4W
R134 1-249-441-11 CARBON 100K 5% 1/4W
R135 1-249-408-11 CARBON 180 5% 1/4W
Ver 1.1
