Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
84
STR-DA1000ES/DB790
R136 1-249-408-11 CARBON 180 5% 1/4W
R137 1-249-428-11 CARBON 8.2K 5% 1/4W
R138 1-249-428-11 CARBON 8.2K 5% 1/4W
R139 1-249-441-11 CARBON 100K 5% 1/4W
R140 1-249-441-11 CARBON 100K 5% 1/4W
R141 1-247-807-31 CARBON 100 5% 1/4W
R142 1-247-807-31 CARBON 100 5% 1/4W
R143 1-249-441-11 CARBON 100K 5% 1/4W
R144 1-249-441-11 CARBON 100K 5% 1/4W
R145 1-249-413-11 CARBON 470 5% 1/4W
R146 1-249-413-11 CARBON 470 5% 1/4W
R147 1-249-441-11 CARBON 100K 5% 1/4W
R148 1-249-441-11 CARBON 100K 5% 1/4W
R151 1-249-417-11 CARBON 1K 5% 1/4W
R152 1-249-417-11 CARBON 1K 5% 1/4W
R153 1-249-421-11 CARBON 2.2K 5% 1/4W
R154 1-249-421-11 CARBON 2.2K 5% 1/4W
R155 1-249-417-11 CARBON 1K 5% 1/4W
R156 1-249-417-11 CARBON 1K 5% 1/4W
R171 1-249-429-11 CARBON 10K 5% 1/4W
R172 1-249-431-11 CARBON 15K 5% 1/4W
R173 1-249-425-11 CARBON 4.7K 5% 1/4W
R174 1-249-431-11 CARBON 15K 5% 1/4W
R175 1-249-429-11 CARBON 10K 5% 1/4W
R176 1-249-429-11 CARBON 10K 5% 1/4W
R177 1-249-429-11 CARBON 10K 5% 1/4W
R178 1-249-417-11 CARBON 1K 5% 1/4W
R181 1-249-429-11 CARBON 10K 5% 1/4W
R182 1-249-431-11 CARBON 15K 5% 1/4W
R183 1-249-425-11 CARBON 4.7K 5% 1/4W
R184 1-249-431-11 CARBON 15K 5% 1/4W
R185 1-249-429-11 CARBON 10K 5% 1/4W
R186 1-249-429-11 CARBON 10K 5% 1/4W
R187 1-249-429-11 CARBON 10K 5% 1/4W
0R840 1-249-399-11 CARBON 33 5% 1/4W F
0R845 1-249-399-11 CARBON 33 5% 1/4W F
**************************************************************
A-4733-521-A COMP-V BOARD, COMPLETE (DA1000ES)
A-4733-546-A COMP-V BOARD, COMPLETE (DB790)
***********************
< CAPACITOR >
C351 1-127-868-11 CERAMIC 2200PF 10% 50V
C360 1-128-818-11 CERAMIC 560PF 5% 50V
(DA1000ES)
C361 1-128-816-11 CERAMIC 390PF 5% 50V
(DA1000ES)
C362 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C363 1-128-801-11 CERAMIC 22PF 5% 50V
(DA1000ES)
C364 1-162-201-31 CERAMIC 12PF 5% 50V
(DA1000ES)
C365 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C366 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DA1000ES)
C367 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DA1000ES)
C368 1-126-963-11 ELECT 4.7uF 20% 50V
(DA1000ES)
C369 1-130-495-00 MYLAR 0.1uF 5% 50V
(DA1000ES)
C370 1-162-201-31 CERAMIC 12PF 5% 50V
(DA1000ES)
C371 1-128-801-11 CERAMIC 22PF 5% 50V
(DA1000ES)
C372 1-162-201-31 CERAMIC 12PF 5% 50V
(DA1000ES)
C373 1-128-801-11 CERAMIC 22PF 5% 50V
(DA1000ES)
C374 1-126-935-11 ELECT 470uF 20% 16V
(DA1000ES)
C375 1-126-965-11 ELECT 22uF 20% 50V
(DA1000ES)
C376 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C377 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DA1000ES)
C378 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DA1000ES)
C379 1-128-812-11 CERAMIC 180PF 5% 50V
(DA1000ES)
C380 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DA1000ES)
C381 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DA1000ES)
C382 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DA1000ES)
C383 1-104-665-11 ELECT 100uF 20% 25V
(DA1000ES)
C384 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DA1000ES)
C385 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DA1000ES)
C386 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DA1000ES)
C387 1-126-959-11 ELECT 0.47uF 20% 50V
(DA1000ES)
C388 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DA1000ES)
C389 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DA1000ES)
C390 1-104-665-11 ELECT 100uF 20% 25V
(DA1000ES)
C391 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C392 1-127-888-11 CERAMIC 0.1uF 10% 50V
(DA1000ES)
C393 1-162-203-31 CERAMIC 15PF 5% 50V
(DA1000ES)
C394 1-126-961-11 ELECT 2.2uF 20% 50V
(DA1000ES)
C395 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DA1000ES)
C396 1-126-963-11 ELECT 4.7uF 20% 50V
(DA1000ES)
C397 1-127-876-11 CERAMIC 0.01uF 10% 50V
(DA1000ES)
C398 1-128-806-11 CERAMIC 56PF 5% 50V
(DA1000ES)
