Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
88
STR-DA1000ES/DB790
DIGITAL
C1218 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1220 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DB790: AEP, UK)
C1227 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1229 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1230 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1233 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1234 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C1235 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C1309 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1310 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1401 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1402 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C1402 1-128-840-11 ELECT 47uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1402 1-135-708-11 ELECT 47uF 16V
(DB790: AEP, UK)
C1403 1-119-824-11 ELECT 10uF 20% 50V
(DB790: SP, MY, TW, KR, AUS, CH)
C1403 1-126-964-11 ELECT 10uF 20% 50V
(DA1000ES)
C1403 1-135-743-11 ELECT 10uF 50V
(DB790: AEP, UK)
C1404 1-119-823-11 ELECT 4.7uF 20% 50V
(DB790: SP, MY, TW, KR, AUS, CH)
C1404 1-126-963-11 ELECT 4.7uF 20% 50V
(DA1000ES)
C1404 1-135-742-11 ELECT 4.7uF 50V
(DB790: AEP, UK)
C1405 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C1406 1-119-823-11 ELECT 4.7uF 20% 50V
(DB790: SP, MY, TW, KR, AUS, CH)
C1406 1-126-963-11 ELECT 4.7uF 20% 50V
(DA1000ES)
C1406 1-135-742-11 ELECT 4.7uF 50V
(DB790: AEP, UK)
C1407 1-119-824-11 ELECT 10uF 20% 50V
(DB790: SP, MY, TW, KR, AUS, CH)
C1407 1-126-964-11 ELECT 10uF 20% 50V
(DA1000ES)
C1407 1-135-743-11 ELECT 10uF 50V
(DB790: AEP, UK)
C1408 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C1409 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C1409 1-128-840-11 ELECT 47uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1409 1-135-708-11 ELECT 47uF 16V
(DB790: AEP, UK)
C1410 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1411 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1413 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1414 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1415 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1417 1-126-935-11 ELECT 470uF 20% 16V
(DA1000ES)
C1417 1-127-720-11 ELECT 470uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1417 1-135-711-11 ELECT 470uF 16V
(DB790: AEP, UK)
C1418 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1501 1-126-924-11 ELECT 330uF 20% 10V
(DA1000ES)
C1501 1-128-833-11 ELECT 330uF 10V
(DB790)
C1502 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1504 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C1504 1-127-719-11 ELECT 220uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1504 1-135-710-11 ELECT 220uF 16V
(DB790: AEP, UK)
C1505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1506 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DA1000ES)
C1507 1-119-824-11 ELECT 10uF 20% 50V
(DB790: SP, MY, TW, KR, AUS, CH)
C1507 1-126-964-11 ELECT 10uF 20% 50V
(DA1000ES)
C1507 1-135-743-11 ELECT 10uF 50V
(DB790: AEP, UK)
C1508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1511 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1512 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1513 1-119-824-11 ELECT 10uF 20% 50V
(DB790: SP, MY, TW, KR, AUS, CH)
C1513 1-126-964-11 ELECT 10uF 20% 50V
(DA1000ES)
C1513 1-135-743-11 ELECT 10uF 50V
(DB790: AEP, UK)
C1514 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1522 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C1523 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C1524 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C1524 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1524 1-135-709-11 ELECT 100uF 16V
(DB790: AEP, UK)
C1532 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C1533 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C1534 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C1534 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1534 1-135-709-11 ELECT 100uF 16V
(DB790: AEP, UK)
C1542 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C1543 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C1544 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
Ver 1.1
