Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
89
STR-DA1000ES/DB790
C1544 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1544 1-135-709-11 ELECT 100uF 16V
(DB790: AEP, UK)
C1552 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C1553 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C1554 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C1554 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1554 1-135-709-11 ELECT 100uF 16V
(DB790: AEP, UK)
C1562 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C1563 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C1564 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C1564 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1564 1-135-709-11 ELECT 100uF 16V
(DB790: AEP, UK)
C1572 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C1573 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C1574 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C1574 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1574 1-135-709-11 ELECT 100uF 16V
(DB790: AEP, UK)
C1582 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
C1583 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C1584 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C1584 1-127-718-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1584 1-135-709-11 ELECT 100uF 16V
(DB790: AEP, UK)
C1592 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V
(DA1000ES)
C1593 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
(DA1000ES)
C1594 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C1601 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1602 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1606 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C1606 1-128-840-11 ELECT 47uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1606 1-135-708-11 ELECT 47uF 16V
(DB790: AEP, UK)
C1608 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1609 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1610 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1611 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1612 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1613 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1614 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C1617 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1618 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1619 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1620 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1624 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1626 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1627 1-119-824-11 ELECT 10uF 20% 50V
C1628 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C1629 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C1631 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1634 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1635 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1638 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1639 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1640 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1658 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1659 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1905 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1906 1-126-935-11 ELECT 470uF 20% 16V
(DA1000ES)
C1906 1-127-720-11 ELECT 470uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1906 1-135-711-11 ELECT 470uF 16V
(DB790: AEP, UK)
C1908 1-126-935-11 ELECT 470uF 20% 16V
(DA1000ES)
C1908 1-127-720-11 ELECT 470uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1908 1-135-711-11 ELECT 470uF 16V
(DB790: AEP, UK)
C1909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1910 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C1910 1-128-832-11 ELECT 220uF 20% 10V
(DB790)
C1911 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1912 1-126-935-11 ELECT 470uF 20% 16V
(DA1000ES)
C1912 1-127-720-11 ELECT 470uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1912 1-135-711-11 ELECT 470uF 16V
(DB790: AEP, UK)
C1913 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1914 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C1914 1-128-840-11 ELECT 47uF 20% 16V
(DB790: SP, MY, TW, KR, AUS, CH)
C1914 1-135-708-11 ELECT 47uF 16V
(DB790: AEP, UK)
C1915 1-135-708-11 ELECT 47uF 16V
(DB790: AEP, UK)
C1916 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DB790: AEP, UK)
< CONNECTOR >
CN1101 1-764-867-41 CONNECTOR, BOARD TO BOARD 20P
CN1102 1-764-867-41 CONNECTOR, BOARD TO BOARD 20P
CN1103 1-569-060-11 SOCKET, CONNECTOR 11P
(EXCEPT DB790: AEP, UK)
CN1103 1-569-321-11 SOCKET, CONNECTOR 15P (DB790: AEP, UK)
CN1104 1-784-923-11 PIN, CONNECTOR 7P
