Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
90
STR-DA1000ES/DB790
DIGITAL
CN1105 1-784-788-11 CONNECTOR, FFC 27P
CN1106 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN1107 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN1110 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< DIODE >
D1001 8-719-016-74 DIODE 1SS352
D1101 8-719-016-74 DIODE 1SS352
D1601 8-719-016-74 DIODE 1SS352
D1603 8-719-016-74 DIODE 1SS352
D1905 8-719-053-18 DIODE 1SR154-400TE-25
D1906 8-719-053-18 DIODE 1SR154-400TE-25
D1907 8-719-053-18 DIODE 1SR154-400TE-25
< FERRITE BEAD >
FB1101 1-469-152-11 FERRITE 0uH
FB1102 1-469-152-11 FERRITE 0uH
FB1104 1-414-813-11 FERRITE 0uH
FB1105 1-414-813-11 FERRITE 0uH
FB1201 1-469-152-11 FERRITE 0uH
FB1202 1-469-152-11 FERRITE 0uH
FB1203 1-414-813-11 FERRITE 0uH
FB1401 1-469-152-11 FERRITE 0uH
FB1407 1-414-813-11 FERRITE 0uH
FB1501 1-469-152-11 FERRITE 0uH
FB1502 1-469-152-11 FERRITE 0uH
FB1503 1-414-813-11 FERRITE 0uH
FB1601 1-469-152-11 FERRITE 0uH
FB1602 1-469-152-11 FERRITE 0uH
FB1603 1-469-152-11 FERRITE 0uH
FB1604 1-469-152-11 FERRITE 0uH
FB1605 1-469-152-11 FERRITE 0uH
< IC >
IC1101 8-759-825-15 IC LC89056W-E
IC1102 8-759-242-70 IC TC7WU04F
IC1103 8-759-926-17 IC SN74HC153ANS
IC1104 6-600-014-01 IC TORX141L (DIGITAL OPTICAL DVD IN)
IC1105 6-600-014-01 IC TORX141L (DIGITAL OPTICAL TV/SAT IN)
IC1106 6-600-014-01 IC TORX141L (DIGITAL OPTICAL MD IN)
IC1107 6-600-012-01 IC TOTX141L (DIGITAL OPTICAL MD OUT)
IC1201 6-702-047-01 IC CXD9718Q
IC1202 6-700-983-01 IC IS61LV6416-15T (ICSI)
IC1204 8-759-546-74 IC TC7WH157FU (TE12R)
IC1401 8-759-560-56 IC PCM1800E/2K
IC1402 8-759-636-55 IC M5218AFP
IC1403 8-759-231-53 IC TA7805S
IC1501 8-759-825-12 IC PCM1604Y/2K
IC1502 8-759-825-13 IC PCM1748E/2K
IC1503 8-759-196-96 IC TC7SH08FU-TE85R
IC1504 8-759-546-74 IC TC7WH157FU (TE12R) (DA1000ES)
IC1521 8-759-636-55 IC M5218AFP
IC1541 8-759-636-55 IC M5218AFP
IC1561 8-759-636-55 IC M5218AFP
IC1581 8-759-636-55 IC M5218AFP
IC1601 6-802-990-01 IC MB90478PF-G-148-BND
IC1602 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC1604 8-759-641-86 IC BR24C16F-E2
IC1901 6-701-887-02 IC SI-3004KWF
IC1902 8-759-604-32 IC M5F7810L
IC1903 8-759-647-10 IC uPC2933HF
IC1904 8-759-647-10 IC uPC2933HF
IC1905 8-759-445-59 IC BA033T (DB790: AEP, UK)
< JACK >
J1101 1-784-431-11 JACK, PIN 1P (DIGITAL COAXIAL IN
ASSIGNABLE DVD CD/SACD)
J1102 1-563-330-11 JACK (CONTROL A1II)
< SHORT >
JR1112 1-216-864-11 SHORT CHIP 0 (EXCEPT DB790: AEP, UK)
JR1113 1-216-864-11 SHORT CHIP 0 (EXCEPT DB790: AEP, UK)
JR1114 1-216-864-11 SHORT CHIP 0 (EXCEPT DB790: AEP, UK)
JR1121 1-216-864-11 SHORT CHIP 0
JR1200 1-216-864-11 SHORT CHIP 0
JR1201 1-216-864-11 SHORT CHIP 0
JR1501 1-216-864-11 SHORT CHIP 0 (DB790)
JR1688 1-216-864-11 SHORT CHIP 0
< SHORT >
L1901 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q1601 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1602 8-729-230-49 TRANSISTOR 2SC2712-YG
Q1603 8-729-230-49 TRANSISTOR 2SC2712-YG
Q1607 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R1100 1-216-857-11 METAL CHIP 1M 5% 1/10W
R1101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1104 1-216-809-11 METAL CHIP 100 5% 1/10W
R1105 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1106 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1107 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R1108 1-216-809-11 METAL CHIP 100 5% 1/10W
R1109 1-216-864-11 SHORT CHIP 0
R1110 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1111 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1112 1-216-809-11 METAL CHIP 100 5% 1/10W
R1113 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1114 1-216-809-11 METAL CHIP 100 5% 1/10W
R1115 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1116 1-218-285-11 METAL CHIP 75 5% 1/10W
R1117 1-216-817-11 METAL CHIP 470 5% 1/10W
R1118 1-216-853-11 METAL CHIP 470K 5% 1/10W
R1119 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1120 1-216-809-11 METAL CHIP 100 5% 1/10W
R1121 1-216-809-11 METAL CHIP 100 5% 1/10W
R1122 1-216-809-11 METAL CHIP 100 5% 1/10W
R1123 1-216-809-11 METAL CHIP 100 5% 1/10W
R1124 1-216-809-11 METAL CHIP 100 5% 1/10W
R1127 1-216-809-11 METAL CHIP 100 5% 1/10W
R1201 1-216-833-11 METAL CHIP 10K 5% 1/10W
