Page #91 background imageLoading...
Page #91 background image
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
91
STR-DA1000ES/DB790
R1202 1-216-809-11 METAL CHIP 100 5% 1/10W
R1203 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1205 1-216-809-11 METAL CHIP 100 5% 1/10W
R1206 1-216-809-11 METAL CHIP 100 5% 1/10W
R1207 1-216-809-11 METAL CHIP 100 5% 1/10W
R1208 1-216-809-11 METAL CHIP 100 5% 1/10W
R1209 1-216-809-11 METAL CHIP 100 5% 1/10W
R1210 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1212 1-216-813-11 METAL CHIP 220 5% 1/10W
R1213 1-216-813-11 METAL CHIP 220 5% 1/10W
R1214 1-216-813-11 METAL CHIP 220 5% 1/10W
R1215 1-216-813-11 METAL CHIP 220 5% 1/10W
R1216 1-216-813-11 METAL CHIP 220 5% 1/10W
R1217 1-216-813-11 METAL CHIP 220 5% 1/10W
R1218 1-216-813-11 METAL CHIP 220 5% 1/10W
R1219 1-216-813-11 METAL CHIP 220 5% 1/10W
R1220 1-216-813-11 METAL CHIP 220 5% 1/10W
R1221 1-216-813-11 METAL CHIP 220 5% 1/10W
R1222 1-216-813-11 METAL CHIP 220 5% 1/10W
R1224 1-216-809-11 METAL CHIP 100 5% 1/10W
R1226 1-216-864-11 SHORT CHIP 0
R1304 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1305 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1308 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1314 1-216-864-11 SHORT CHIP 0
R1364 1-216-864-11 SHORT CHIP 0
R1401 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1421 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1422 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1424 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1431 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1432 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1434 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1437 1-216-809-11 METAL CHIP 100 5% 1/10W
R1501 1-216-809-11 METAL CHIP 100 5% 1/10W
R1502 1-216-809-11 METAL CHIP 100 5% 1/10W
R1503 1-216-809-11 METAL CHIP 100 5% 1/10W
R1504 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1505 1-216-809-11 METAL CHIP 100 5% 1/10W
R1506 1-216-809-11 METAL CHIP 100 5% 1/10W
R1507 1-216-809-11 METAL CHIP 100 5% 1/10W
R1508 1-216-809-11 METAL CHIP 100 5% 1/10W
R1509 1-216-809-11 METAL CHIP 100 5% 1/10W
R1512 1-216-809-11 METAL CHIP 100 5% 1/10W
R1520 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1521 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1522 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1523 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1524 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1530 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1531 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1532 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1533 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1534 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1540 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1541 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1542 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1543 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1544 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1550 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1551 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1552 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1553 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1554 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1560 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1561 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1562 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1563 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1564 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1570 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1571 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1572 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1573 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1574 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1580 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R1581 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1582 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1583 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1584 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1590 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
(DA1000ES)
R1591 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
(DA1000ES)
R1592 1-216-837-11 METAL CHIP 22K 5% 1/10W
(DA1000ES)
R1593 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DA1000ES)
R1594 1-216-845-11 METAL CHIP 100K 5% 1/10W
(DA1000ES)
R1600 1-216-809-11 METAL CHIP 100 5% 1/10W
R1601 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1602 1-216-809-11 METAL CHIP 100 5% 1/10W
R1603 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1604 1-216-809-11 METAL CHIP 100 5% 1/10W
R1605 1-216-809-11 METAL CHIP 100 5% 1/10W
R1606 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1607 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1608 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1609 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1610 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1611 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1612 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1613 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1614 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1615 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1616 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1617 1-216-809-11 METAL CHIP 100 5% 1/10W
R1618 1-216-809-11 METAL CHIP 100 5% 1/10W
R1619 1-216-809-11 METAL CHIP 100 5% 1/10W
R1620 1-216-809-11 METAL CHIP 100 5% 1/10W
R1621 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1622 1-216-809-11 METAL CHIP 100 5% 1/10W
R1623 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1624 1-216-833-11 METAL CHIP 10K 5% 1/10W
