2-4 (E)
VPL-EX100
2-3-4. Angle Detect Sensor Adjustment
1. Enter the service mode. (Refer to Section 2-3-2.)
2. Select the menus in the following order: Device → Other → 20 Other/X Tilt.
3. Place the unit on the table parallel to the top side of the unit.
4. Save the memory this value of the X TILT in 22 Other/X Tilt C0.
5. Tilt the unit to a 90-degree downward direction.
6. Calculate the following with this value of the X TILT.
(X TILT C1) = ((Value of the X TILT) _ (X TILT C0)) x 33/8 + X TILT C0
7. Enter the result of step 6 in 23 Other/X Tilt C1.
8. Tilt the unit to a 90-degree upward direction.
9. Calculate the following with this value of the X TILT.
(X TILT C0) = ((Value of the X TILT) _ (X TILT C0)) x 33/8 + X TILT C0
10. Enter the result of step 9 in 24 Other/X Tilt C2.
11. Select the menus in the following order: Device → Memory Save. Select [Yes], and press the
[ENTER] key to save.
2-4. Software Update
2-4-1. Preparation
Required equipment/Tools
. Personal computer (PC)
. RS-232C cross cable: RS-232C connection
. USB cable: USB connection
. Sub Flash upgrader for Sony Projector: Updater for Sub
. Pixelworks ImageProcessor SDK FlashUpgrader/SONY Custom:
Updater for Main (scan converter)
. Anem Updater: Updater for Ext (Network)
. Linux Gadget Serial Driver: Gadget Serial Driver
. USBX board (A-1797-932-A: X kit assembly): USB connection
m
. For obtaining the each application and version upgrade fi le, contact your local Sony Sales Offi ce/
Service Center.
. For Ext (Network) updating PC, the installation of the softwares below is required.
Name File name Remarks
RXTXComPort RXTXComPort.zip
Flip Flip_Installer_3_3_4.exe
Java Runtime Environment jre-6u16-windows-i586.exe Version 6 Update16 or later
.NET Framework NetFx20SP2_x86.exe Version 2.0 SP2 or later
C run-time library 7 msvcr71.dll
