2-10 (E)
VPL-EX100
2-5. Quick Access
2-5-1. Preparation
Required equipment/Tools
. Personal computer (PC): RS-232C interface equipped
. RS-232C cross cable
. 3Dgamma QuickAccess: Executable: QuickAccess.exe
Preparation
1. Install the 3Dgamma QuickAccess in PC.
2. Connect this unit with PC. (Refer to RS-232C connection in Section 2-4-1.)
2-5-2. Saving of 3Dgamma/LookUpTable/Main Board Data
1. Connect the AC plug and set this unit to standby state.
2. Press the I/O button on this unit.
The lamp lights and the image is displayed.
3. Double-click QuickAccess.exe to start the application.
4. Select a target model on the Model pull-down menu.
5. Select Save on the Load/Save pull-down menu.
6 Select the data type (3Dgamma/LookUpTable/Main Board) on the 3dgm/Lut pull-down menu.
7. Click the [Next] button.
8 Click the [Browse...] button.
The fi le selection window is displayed.
9. Select the destination fi le for the obtained data.
10. Click the [Next] button.
11. Select the serial port used for connecting PC on the Serial Port pull-down menu.
Upper line: Serial port number used for connecting PC
Lower line: 38400 (not selectable)
12. Click the [Next] button.
The window displaying the model name of this unit, serial number, and the fi le path of the destination
of the obtained data to save is displayed.
13. Click the [OK] button.
The saving starts. Completed is displayed after completed.
14. Press the I/O button and set this unit to standby state.
15. Disconnect the AC plug.
16. Click the [Complete] button.
