CRANEX
®
Novus e 3. Circuit Boards - L1600, Z-Motor Driver
Service manual 37
L1600 - Field replaceable parts
NOTE:
The fuses used MUST be the approved type, UL listed
and CSA certifi ed.
Approved fuses:
Fuse F1
2AT/250VAC Cooper Bussmann MDL-2
2AT/250VAC Littelfuse 0313002 HXP
Fuse F2
8AF/250V Littelfuse 0312008 312 series
8AF/250V Cooper Bussman AGE
Dimensions 6.3 mm x 32 mm.
L1600 - Description
L1600 (Z-Motor Driver) controls the AC-motor that
drives the unit up and down. Membrane switches on
the side of the vertical carriage are used to activate the
AC-motor.
Micro switches at the top and bottom of the column
monitor the upper and lower positions of the Z-move-
ment. Based on the logic on the circuit board, the move-
ment of the AC motor is enabled or prohibited. Three
triacs control the Z-motor currents. Outputs are opto-
coupled from the user inputs with TLP3063 circuits. The
board also includes light controls for the laser position-
ing lights.
L1600 also sets the autotransformer input winding.
There are three SET signals, SET 100V, SET 115V and
SET 230V that control what mains voltage goes to what
input winding of the autotransformer.
The auto transformer output voltage is always 230 VAC
