15.0: TALKBACK & OSCILLATOR
TALKBACK & OSCILLATOR
Most main oscillator and talkback controls are grouped together in the Master Bay, though there is a Talkback
Assignment button [TB ASSN] in the VISTONICS button group, which allows manual assignment of the talkback
group bus destinations.
Talkback is a independent signal path, normally from a microphone input to group and physical outputs, activated with
push-to-talk talkback buttons on the console itself. It is most often used to allow the console operator to talk to
assistants, performers, and so on. There is also a talkback return, which is an independent input path to the monitor
section - most often used to allow assistants and performers to talk directly to the console operator.
The oscillator is a signal generator provided as a general-purpose calibration and checking tool.
