5.8: LABELLING
OPS OVERVIEW > LABELLING
The console labelling system is displayed on a touch-screen area whenever the labelling of a channel, output, cue,
le, or other named parameter or item is required. For example, you can label an input channel by touching the
channel’s input area on the touch screen then pressing the {CH LABEL} button in the VST area.
Labelling can be done with the displayed on-screen keyboard or an external USB keyboard. The on-screen keyboard
is context sensitive and shows only the allowed character and symbols.
Long Labels are displayed along the bottom of each touchscreen and can contain up to 10 characters. Short labels
are displayed on the LCD displays located on the Fader panel and can contain up to six characters.
