The console comes with eight stereo Lexicon FX processors. Each FX Unit can be inserted into any Output/Main Mas-
ter bus or into any Input Channel, or it can be patched as an FX Return to an Input Channel or fed from an Aux send.
Algorithm selection and parameter adjustment is integrated into the console’s Vistonics II environment - editable either
from the relevant channel’s bay, or from the Master Bay via the FX Overview page in the main menu.
All Parameters from the four Effects Units and for all Effects Type are stored in the desk Snapshots.
LEXICON Effects Format
Depending on the selected effect type, the FX processor works internally in one of three formats: Mono, Mono In/Ste-
reo Out, or Stereo In/Stereo Out.
The FX processor always has Stereo Inputs and Outputs. If the FX Type needs only a Mono Input, the Left and Right
Input Signal are summed together. If the FX Type outputs only a Mono Signal then the Output Signal is distributed to
both the Left and Right Outputs. The MIX Parameter adjusts the ratio between the original (dry) signal and the effects
(wet) signal. The stereo format of the dry signal will be maintained.
Lexicon FX
