10.1: MONITORING CONTROLS
MONITORING > CONTROLS
MNTR B - Monitor A/B Select
Select either the A or the B monitor to be displayed on the meter, to be controlled by the fader,
and to be switched on and off by the [ON] switch.
Both Monitor A and B sources are always active - (respecting their individual On/O status'). The MNTR B button
changes metering and control assignment.
Monitor Fader
Control monitoring volume level.
AFL and PFL indication
These two LEDs show if an active solo is a PFL or an AFL.
Monitoring Setup
Display the Monitor Setup Page on the master screen.
The [SETUP] key glows blue when it is active.
Headphones Level
Control the headphones volume level.
The headphone output socket is located under the armrest at the front of the console, and is designed for head-
phones with impedances in the range 50-600 Ohms.
Solo Trim
Trims source SOLO Level.
This control is SOLO context sensitive. It is possible to set a dierent trim for each of the 32 outputs in addition to
a global input solo trim level.
To Next Page
