6.5.5: OUTPUT
INPUT CHANNEL > OUTPUT BLOCK: PAN, INSERT, DIR OUT, DELAY
LR On
Routes the channel signal to the Left and Right masters.
Centre On
Routes the channel signal to the Centre master bus.
Panning Mode
Set either LR or LCR Mode.
In LR Mode only Pan is available, though routing to the C master bus is still possible. With LCR mode enabled, the
width parameter becomes available.
Insert Patch
Select and assign physical I/O, internal FX processor, or BSS DPR 901 ii EQ for the insert send
and return.
Insert points provide a send and return path that interrupts the channel signal flow.
In any Insert Select page, all available insert points can be patched to physical I/O by touching the on-screen
(SETUP) button. You can return to insert assignment by touching the (SETUP) button again. In Insert SETUP
mode you can choose send and return I/O from any of the available physical inputs and outputs, and you can pair
inserts.
You can assign input channel inserts to any unused insert point or to an available internal FX unit or BSS
DPR 901 ii EQ. If you try to select an insert point that has already been assigned, you will be oered the option to
‘steal’ that insert.
Insert Point
Select the point in the input channel's signal path for the insert point 'tap'.
Options are post-HPF/Pre-processing, post-processing/pre-fader, or post-fader.
