2.0: SPECIFICATIONS
®
2.0: SPECIFICATIONS
SPECIFICATIONS
Frequency Response
Stagebox Mic input to Line output: +0/-1dB, 20Hz-20kHz
AES/EBU In to AES/EBU Out: +0/-0.2dB, 20Hz-20kHz
T.H.D. & NOISE
Stagebox Mic In (min gain) to Local Line Out:
22Hz-22kHz, <0.003% @ 1kHz
Stagebox Mic In (max gain) to Local Line Out:
22Hz-22kHz, <0.020% @ 1kHz
Local Line In to Line Out:
22Hz-22kHz, <0.003% @ 1kHz
Mic Input E.I.N (22Hz-22kHz bandwidth, unweighted):
<-126dBu (150Ω source)
Residual Noise, Stagebox line output; no inputs routed:
Mix fader @0dB: -91dBu
CMRR, Stagebox Mic input: 80dB @ 1kHz
Sampling Frequency
48kHz or 96kHz
Latency
Stagebox Mic Input to Local Line output:
<2ms @48kHz; <1ms @96kHz
AES/EBU Input Sample Rate
32–108kHz (with SRC enabled)
DSP resolution
40-bit oating point
Clocks
Internal clock accuracy: <+/-50ppm
Internal clock jitter: <+/-5ns
External Sync: BNC Wordclock
Input & Output Levels
Mic Inputs: +28dBu max
Line Inputs: +22dBu max
Line Outputs: +22dBu max
Nominal Operating Level: +4dBu (-18dBFS)
Input & Output Impedances
Mic Inputs: 10kΩ
All other analogue Inputs: >10kΩ
Line Outputs: <75Ω
AES/EBU Outputs: 110Ω
Oscillator
20Hz to 20kHz/Pink/White Noise, variable level
EQ (Inputs and bus Outputs)
HF: 20Hz-20kHz, +/-18dB, Q= 0.3-8.7 or shelving
Hi-Mid: 20Hz-20kHz, +/-18dB, Q=0.3-8.7
Lo-Mid: 20Hz-20kHz, +/-18dB, Q=0.3-8.7
LF: 20Hz-20kHz, +/-18dB, Q= 0.3-8.7 or shelving
Stagebox HP Filter: 80Hz xed, 12dB per octave
Channel HP lter: 20Hz-600Hz, 18dB per octave
Channel LP lter: 1kHz-20kHz, 18dB per octave
Metering
Internal 20-segment LED bargraphs plus 9-segment gain
reduction meters for all inputs and Outputs.
Peak hold: Variable from 0-2s.
Power / Operation
Mains Voltage operating range: 90-264V, 47-63Hz,
autoranging
Mains Power Consumption: 300W
Operating Temperature Range: 0°C – 45°C
(32°F – 113°F)
Relative Humidity: 0% – 90%, non-condensing Ta=40°C
(104°F)
Storage Temperature Range: -20°C to 60°C
(-4°F – 140°F)
E & OE.
Soundcraft reserves the right to change specications without notice.
