15.2: OSCILLATOR SETUP
OSCILLATOR > SETUP
Oscillator To Talkback
Route the oscillator signal to the TB Bus (replaces the TB signal).
Oscillator Frequency
Adjust the Oscillator sine wave Frequency in the range 20Hz to 20kHz.
Oscillator Bus Assignment
Used in conjunction with the Oscillator to Bus touch screen switch.
Opens an output assignment page where you can select any of the 32 group busses or the Mix L, R, and C out-
puts.
Oscillator On
Activate the console's oscillator.
Oscillator Gain
Adjust the oscillator output level
Oscillator Output
Assign the oscillator to individual physical outputs.
Opens an output assignment page with all available physical outputs available.
