7.1 LCR MASTERS
7.1: LCR MASTERS
OUTPUTS > LCR MIX MASTER BUSSES
Isolate
Isolate the LRC Masters from snapshot recall or Show Recall (with global ltering active).
See the Snapshots / Global Filtering reference for more detail.
On
Bus On/Off (Mute).
LCR Select
Access the LCR Master Busses processing page.
Gives access to the processing blocks in the Master LRC outputs via the touch screen area of the Master Bay
Vistonics.
LCR Fader
Control the output levels of the LRC Masters
The output levels of the LRC Master outputs are always controlled by their dedicated faders. Those faders are
never used for anything else.
L/C/R Link setup
Set up LRC Master bus EQ and GEQ linking.
Left and Right busses can be linked, or the Centre bus can be added to the linked L and R so that all three busses
can be adjusted together. It is not possible to link Left and Centre or Right and Centre. The default state, loaded
with Default Show Files, is for LINK to be set to ON for LCR busses, both EQ and GEQ.
Access EQ
Adjust the parametric EQ for this Master.
The output bus parametric EQ is the same is used for the input channel EQ. Please see the input channel refer-
ence for more detail.
