24. MIDI IMPLEMENTATION CHART
Function HEX Code Description Compatibility
Nota On 9nH kk vv
MIDI channel n(0-15) note ON
kk(1-127), velocity vv(1-127).
vv=0 means Note OFF
MIDI
Nota O 8nH kk vv
MIDI channel n(0-15) note OFF
kk(1-127). vv is don’t care.
MIDI
Pitch Bender EnH bl bh
Pitch bend as specied by bh|bl (14 bits)
Maximum swing is +/- 1 tone.
Can be changed using “ pitch bend
sensitivity “.
Center position is 00H 40H
GM
Program Change CnH pp
Program (patch) change. Specic action
on channel 10 (n=9) : select drumset.
Refer to sounds / drumset list. Drumsets
can be assigned to other channels (see
SYSEX MIDI channel to part assign and
part to rhythm allocation)
GM/GS
Aftertouch Canale DnH vv
vv pressure value.
Eect set using Sys. Ex.
40H 2nH 20H-26H
MIDI
MIDI RESET FFH Reset to power-up condition ALL
Control Change 0 BnH 00H cc
Bank select : Refer to sounds list.
No action on drumset.
GS
Control Change 1 BnH 01H cc
Modulation wheel. Rate and maximum
depth can be set using SYSEX
MIDI
Control Change 5 BnH 05H cc Portamento time MIDI
Control Change 6 BnH 06H cc
Data entry: provides data to RPN and
NRPN
MIDI
Control Change 7 BnH 07H cc Volume (default=100) MIDI
Control Change 10 BnH 0AH cc Pan (default=64 center) MIDI
Control Change 11 BnH 0BH cc Expression (default=127) MIDI/GM
Control Change 64 BnH 40H cc Sustain Pedal (damper) MIDI
Control Change 65 BnH 41H cc Portamento ON/OFF MIDI
Control Change 66 BnH 42H cc Sostenuto Pedal MIDI
Control Change 67 BnH 43H cc Soft Pedal MIDI
