12-7
XPREZZON AND QUBE
O
PERATIONS MANUAL
M ONITOR SETUP
The following table shows the default priority and color of parameter waveforms.
Note:
The Select, Change Position, Numeric Only (*), Change Color, and Rename
settings can be limited through the Clinical Setup tab of Privileged Access. For
details about Clinical Setup, contact your systems administrator.
Parameter Type Description Priority Color
ECG1 Electrocardiogram (first lead) 1 Green
ECG2 Electrocardiogram (second lead) 2 Green
RESP Respiration 3 Blue
VARI Varitrend 4 White
ART Arterial Pressure 5 Red
UA Umbilical Artery Pressure 6 Red
PA Pulmonary Arterial Pressure 7 Yellow
UV Umbilical Vein Pressure 8 Blue
CVP Central Venous Pressure 9 Blue
RAP Right Atrial Pressure 10 Blue
ICP Intracranial Pressure 11 Magenta
LAP Left Atrial Pressure 12 Red
PRS Other Pressure (general) 13 Magenta
ETCO
2
End Tidal CO
2
14 White
SPO
2
Pulse Oximetry (O
2
saturation) 15 Yellow
NIBP Noninvasive Blood Pressure 16 Red
SVO
2
Venous O
2
Saturation 17 Magenta
TCP Partial Pressure of Transcutaneous O
2
18 White
BIS Bispectral Index 19 Blue
GAS Gas Analyzer 20 White
CO Cardiac Output 21 Magenta
CCO Continuous Cardiac Output 22 Magenta
TEMP Temperature 23 White
VENT Ventilator Flexport System Interface 24 White
ANES Anesthesia 25 White
OTHER 26 White
