XPREZZON AND QUBE
O
PERATIONS MANUAL
B ASIC OPERATIONS
To make a recording of all currently shown patient
parameters
1 From the main taskbar, touch the Printer icon twice.
The Recorder menu shows.
2 Touch Record All.
Eight seconds of the currently shown patient parameters are
sent to the printer.
To start a continuous recording
1 From the main taskbar, touch the Printer icon once.
The Continuous Record button shows in the lower left corner of
the display and all parameter keys flash for two seconds.
2 Touch Continuous Record. Touch up to four flashing parameter
keys.
The parameters you selected are sent to the printer.
To stop a continuous recording
1 From the main taskbar, touch the Printer icon once.
When a recording is already in progress the Stop Continuous
Record button shows.
2 Touch Stop Continuous Record.
The recording stops.
How to load paper in the printer
1 Press the release button on the door of the printer.
2 Open the paper tray door.
3 Snap the new roll into place with the paper feeding from the bottom.
4 Pull out 6 to 12 inches of paper.
5 Close the paper tray door.
To identify the printer destination
1 From the main taskbar, touch the Help icon twice.
The Help window shows Recording Destinations. These are the
locations of the printer to which this monitor will print.
Network is the term used for the printer at the central monitor.
Group Recordings
The monitor can be pre-configured to print two sets of recordings, A and B, that
consist of specific beds and patient parameters. These preselected recordings are
always eight seconds in duration. The monitor prints all of the requested
parameters for one patient before printing the parameters for the next patient.
