www.spacelabshealthcare.com
9-10
XPREZZON
AND QUBE
O
PERATIONS MANUAL
TRENDS
Note:
Adjusting the setup in the Trends menu is temporary: it is just for the current
patient. When the patient is discharged, the changes in the Setup menu are not
retained.
To rename a graph
1 From the Trends Setup window, touch the tab for the graph that you want to
adjust properties for.
2 Touch Rename on the right side of the window.
3 Use the onscreen keyboard to enter a new name for the graph.
4 Touch Enter.
To add measurements to a graph
1 From the Trends Setup window, touch the tab for the graph that you want to
adjust the properties for.
2 Touch Add on the upper-right side of the window.
The Measurement Selection dialog box shows.
3 Touch the Show Only Available check box if you want to restrict
the list to measurements that are available for the current
patient.
4 Touch the box in the Selected column for the measurements you want to add
to the category. To select all measurements in a category, select the check
box in the top category row.
5 After you have selected all measurements you want to add, touch OK.
Only four measurements are allowed on each graph.
To delete measurements from a graph
1 From the Trends Setup window, touch the tab for the graph that you want to
adjust properties for.
2 From the measurements list, touch the measurement that you want to
delete.
3 Touch Delete on the upper-right side of the window.
To change the color used to show a
measurement
1 From the Trends Setup window, touch the tab for the graph that you want to
adjust properties for.
2 From the measurement list, touch the measurement that you want to change
the color for.
3 Under Color, in the lower portion of the graph setup tab, touch the panel that
shows the current color for the measurement.
A panel of six colors—magenta, blue, green, yellow, red, and white—shows.
4 Touch the color you want to use for the measurement.
