Spot Align (cont.)
Pressing and releasing button again starts the automatic Spot Alignment
while the beam becomes a rotating fan beam which will search automatically
for the SF803‘s center position in a range up to +45°/ 100%.
Note: The left SF symbol flashes while an additional SF symbol at the right site of the
display indicates the beam movement until the beam is centered at the SF803.
Note: The SF803 needs to be tilted into the direction of the DG813
using the pole adapter when placed at a steep slope position.
When the alignment is finished, the beam moves plumb down to the dialed in grade value.
Automatic Spot Align can be exited any time by pressing and releasing button.
Menu functions – Spot Align (only DG813)
