Line Scan - For a faster second day setup, line scan enables complete
automatically movement of the laser beam to the left and right limits.
Press and release the button at the standard display and select Line Scan
using the and buttons.
Pressing and releasing button activates the Line Scan mode while the laser
beam moves horizontally to the right/left limits and stops at the center position.
When the beam crosses the target press the button to stop the automatic
beam movement.
Corrections for centering the beam at the target’s bulls-eye can be done using
the buttons.
Line Set/Check - Moves the laser beam vertically to its maximum limit
for setting line in a first day setup without a SF803.
Press and release the button and select Line Set/Check
using the and buttons.
Pressing and releasing button activates the Line Set/Check mode.
The beam moves to the 0% position while the flashing Line Set/Check symbol
appears together with a bubble vial.
Menu functions – Line Scan / Line Set Check
