Components Spot Finder SF803

1 - SF803

2 - Target Plate

for Spot Finder

3 - Center Hole

4 - Power Button

5 - Bubble Vial

6 - Battery LED

7 - Mode LED

8 - Red Direction LEDs

9 - IR transmitters/receivers

10 - Marking notches (front and back)

11 - M6 Clamp Mount

12 - Battery door

13 - Latch for Battery Door

14 - Release Tab Target Plate

15 - SF Pole Adapter

13 12

7 3
