Spot Align at the jobsite
Press E again to
start Spot Align
Rotating Fan beam searches for the Spot Finder‘s center;
LEDs indicate the beam movement
All LEDs On confirm
alignment completed
Beam moves down plumb to the dialed in grade value
If the beam stops
flashing,
start laying pipes using
the target plate
