Spectra Precision DG613 User Manual

Spot Match at the jobsite
Rotating Fan beam searches for the Spot Finder‘s center;
LEDs indicate the beam movement
Replace the Spot Finder with the target plate
and proceed laying pipes
All LEDs On confirm Spot Match completed; beam goes through
the SF center hole; display shows the measured grade value
