Operation
—
20 SPECTROTEST —
05.12.2017
Fig. 5: Test probe
No. Display/button Function
1
Status display of the
test probe
 green light
 ready
 red light
 not ready
 Malfunction
 Blinking red
 A measurement is in process
2
“Start measurement” button
Use this button to proceed with the measurement.
This button must kept depressed during the entire
measurement.
3 “Reset” button
This button is used to reset any error messages displayed ob
the PC.
