Theory of Operation
Automatic Routines
The following are routines that the washer-dryer will follow out automatically during all of the wash,
spin, rinse and dry cycles.
Door Locking / Unlocking Routines
Door Locking Summary - The Door Locking Routine will only start if the door is securely closed and
the Door Switch contact is CLOSED.
1. The Door Switch is energized whenever a cycle is started.
2. During the next few seconds, the contacts on the door switch are checked by the Module Board. The
Status/Door Lock light will go SOLID and the cycle will begin.
Door Unlocking Summary - Unlocking will occur ONLY under these conditions:
1. The Main Motor speed equals “0”
2. There is no water in the drum
3. The cycle is fi nished
4. The Cycle Selector is on a ‘Reset’ position and the Status/Door Lock light is blinking SLOWLY
IMPORTANT!
• The door WILL NOT open while ANY cycle is in progress (Wash or Dry).
• The door WILL NOT open when the Status/Door Lock light is blinking QUICKLY, or is
SOLID.
• The door WILL STAY LOCKED for approximately 1-2 min. after the cycle is complete.
DO NOT attempt to open the door UNLESS the Status/Door Lock light is blink-
ing SLOWLY! If you do, the handle could break and replacement costs would
not be covered under the Warranty.
