Component Testing Procedures
Surge Protector Test Points are located on both the Surge Protector and on the CNK Connector. The Surge protector
is connected to the Module Board (See “Connector Locations on the Module Board”). The CNK Connector is on the
Module Board (See “Connector Locations on the Module Board”).
. Power “in” from the Surge Protector Test
Test Points Reading
Surge Protector to CNK A to B 0 ohms
Surge Protector to CNK C to D 1.0 ohms
Fault Codes: N/A
