Diagnosis & Troubleshooting
Fault Code Explanation / Recommended Testing Procedure
F09 File Set-Up Error (Unverifi able Fault)
F10 Missing or Confl icting Pressure Switch Signal
• Verify Pressure Switch connections and wiring. See “Component Testing”.
F11 Drain Pump Power Supply Failure
• Verify Drain Pump connections and wiring, See “Component Testing”.
F12 Communication Failure
• Verify Module Board connections and wiring. See “Component Testing”.
F13 Dry NTC Sensor Open/Shorted Circuit
• Verify NTC Sensor connections and wiring. See “Component Testing”.
• Verify the fan motor is not stuck, obstructed, or open. See “Component Access”.
F14 Dryer Element on, Pressure Switch Sensing Water in Drum
• Verify pressure switch connector and wiring. See “Component Testing”.
F15 Dry Heating Element Relay Malfunction
• Verify Heating Element connections and wiring. See “Component Testing”.
