Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 47
W72RS Mix Proof Non-Seat Lift Valve with External Flush
Item # 1-1/2" 2" 2-1/2" 3" 4" 6"
1 Control Top
3 Actuator
* 4 O-ring, Inner Stem (not shown) Nitrile
N70010 N70010 N70111 N70111 N70111 N70111
* 5 Bearing, Upper Adapter
102757+ 102757+ 106047+ 106047+ 106047+ 101995+
* 6 O-ring, Body (see note 2) EPDM
E70223 E70228 E70232 E70236 E70244 E70258
FKM
V70223 V70228 V70232 V70236 V70244 V70258
8 Stem, Upper Assembly - See note 1, below
* 10 Seat Ring - Tri Ring, Upper EPDM
106031+ 102736+ 107048+ 102488+ 102491+ 102738+
FKM
107990+ 107980+ 107982+ 107974+ 107977+ 108020+
* 11 Seat Ring - Tri Ring, Vent EPDM
106041+ 107693+ 107696+ 107697+ 102490+ 102737+
FKM
107992+ 107984+ 107987+ 107988+ 107976+ 108019+
* 12 Seat Ring - Radial O-ring, Lower EPDM
E80319 E80325 E80329 E80333 E80340 E80354
FKM
V80319 V80325 V80329 V80333 V80340 V80354
* 14a
Quad Ring, Lower EPDM
122689+ 35413+ 34429+ 117561+ 116952+ 122350+
FKM
122690+ 35414+ 35415+ 117562+ 116953+ 122351+
*
14b
Wiping Stem Seal, Lower EPDM
116186+ 116188+ 116198+ 116195+ 116199+ POA
FKM
116187+ 116189+ 116191+ 116196+ 116200+ POA
* 15 Bearing, Lower Seal Retainer
101947+ 102000+ 106049+ 106048+ 102003+ POA
16a
16b
17a Seal Retainer, Quad Ring 106066+ 106067+ 106068+ 106069+ 106070+ 125047+
17b Seal Retainer, Wiping Stem Seal 117444+ 117445+ 117446+ 117447+ 117448+ POA
17c Seal Retainer, Lower Flush, Quad Ring 121374+ 117728+ 122609+ 117736+ 118364+ POA
17d Seal Retainer, Lower Flush, Wiping Stem Seal 119050+ 119035+ 118226+ 117559+ 118253+ POA
18 Clamp 119-30 119-33 119-34 119-51 119-87 119-123
19 Spray Bushing 106030+ 106030+ 118210+ 118210+ 118210+ 118210+
20a/c Adapter 106020+ 106021+ 106022+ 106023+ 106024+ 128651+
20b Adapter, Wiping Stem Seal 119467+ 119468+ 119469+ 119470+ 119471+ POA
* 21a
O-ring, Upper Stem (qty 3 req) EPDM
E70210 E70210 E70214 E70214 E70214 N/A
FKM
E70210 V70210 V70214 V70214 V70214 N/A
* 21c
Quad Ring, Upper Stem (qty 3 req) EPDM
121300+ 121300+ 124163+ 124163+ 124163+ 114221+
FKM
124088+ 124088+ 121299+ 121299+ 121299+ 114223+
*
21b
Wiping Stem Seal, Upper (qty 3 req) EPDM
116183+ 116183+ 116184+ 116184+ 116184+ POA
FKM
115626+ 115626+ 116185+ 116185+ 116185+ POA
24
* 25 O-ring, Flush EPDM
E70010 E70010 E70111 E70111 E70111 E70111
FKM
V70010 V70010 V70111 V70111 V70111 V70111
Notes:
PL5027-CH52
* Recommended Spare Parts
*** See actuator parts lists
1. For items 8, 16, and 24, see W72RS Mix Proof Non-Seat Lift with External Flush Valve Stems Chart.
2.
4. Unless otherwise noted, quantity required is 1.
6. POA = Part # on availability; N/A = not available with this design.
Contact Factory
***
Stem, Lower Assembly - See note 1, below
Stem, Lower Flush - See note 1, below
For one-piece body, qty. 2 are required for item 6 and item 18; for a clamped body, qty. 3 are required.
Stem, Actuator, NSL Flush - See note 1, below
To Next Page
