SPX W Series User Manual

Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 61
W72RS Mix Proof Seat Lift Tank Outlet Valve with External Flush
Item # 2-1/2" 3" 4" 6"
1 Control Top
3 Actuator Assembly
* 4 O-ring, Outer Stem (qty 2 req) Nitrile
N90020 N90020 N90020 N90020
* 5 Bearing, Adapter
106047+ 106047+ 106047+ POA
* 6 O-ring, Body (qty 2 req) EPDM
E70323 E70236 E70244 E70258
FKM
V70323 V70236 V70244 V70258
* 6a O-ring, Leak Chamber EPDM
E70232 E70232 E70236 POA
FKM
V70232 V70232 V70236 POA
8 Stem, Outer (Pipe Side) - See note 1, below
* 10 Seat Ring - Tri Ring, Pipe Side EPDM
107048+ 102488+ 102491+ 102738+
FKM
107902+ 107974+ 107976+ 108020+
* 11 Seat Ring - Tri Ring, Vent EPDM
107696+ 107697+ 102490+ 102737+
FKM
107987+ 107988+ 107977+ 108019+
* 12 Seat Ring - Radial O-ring, Tank Side EPDM
E80329 E80333 E80340 E80354
FKM
V80329 V80333 V80340 V80354
Quad Ring, Leak Chamber EPDM
34429+ 34429+ 117561+ POA
FKM
35414+ 35415+ 117562+ POA
*
15 Bearing, Leak Chamber
106049+ 106049+ 106048+ POA
16 Stem, Inner (Tank Side) - See note 1, below
18 Clamp, Body (qty 2 req) 119-51 119-51 119-87 119-123
18a Clamp, Leak Chamber 119-34 119-34 119-51 POA
20 Adapter, O-ring POA 114925+ 114926+ POA
*
21
O-ring, Adapter (qty 2 req) EPDM
E70214 E70214 E70214 POA
FKM
V70214 V70214 V70214 POA
24
* 25 O-ring, Inner Stem EPDM
E70111 E70111 E70111 E70111
FKM
V70111 V70111 V70111 V70111
40 Tank Flange (see note 2) 114321+ 114832+ 114833+ POA
41 Leak Chamber, Quad Ring 126804+ 126805+ 126802+ POA
* Recommended Spare Parts
PL5027-CH148
*** See actuator parts lists
1.
2. 1/4" tank flange must be ordered separately.
6. POA = Part # on availability; N/A = not available with this design.
*
For items 8, 16, and 24, see W72RS Mix Proof Seat Lift Tank Outlet Valve with External Flush
Stems Chart.
Part Description
14
***
Stem, Actuator - See note 1, below
