Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 65
W72RSP Mix Proof Seat Lift Valve with External Flush
1 Control Top
3 Actuator
* 4 O-ring, Outer Stem (qty 2 req) Nitrile
N90020 N90020 N90020 N90020
* 5 Bearing, Upper Adapter (qty 2 req)
102002+ 102002+ 102002+ POA
* 6 O-ring, Body (qty 4 req) EPDM
E70244 E70244 E70244 E70258
FKM
V70244 V70244 V70244 V70258
8
* 10 Seat Ring - Tri Ring, Upper EPDM
102491+ 102491+ 102491+ 102738+
FKM
107977+ 107977+ 107977+ 108020+
* 11 Seat Ring - Tri Ring, Vent EPDM
102490+ 102490+ 102490+ 102737+
FKM
107976+ 107976+ 107976+ 108019+
* 12 Seat Ring - O-ring, Lower EPDM
E80340 E80340 E80340 E80354
FKM
V80340 V80340 V80340 V80354
* 14a
Quad Ring, Lower EPDM
116952+ 116952+ 116952+ 122350+
FKM
116953+ 116953+ 116953+ 122351+
* 15 Bearing, Lower Seal Retainer
102003+ 102003+ 102003+ 102004+
16
17a Seal Retainer, Quad Ring 106070+ 106070+ 106070+ 125047+
18 Clamp (qty 2 required) 119-87 119-87 119-87 119-123
19 Spray Bushing 118210+ 118210+ 118210+ 118210+
20a Adapter, O-ring or Quad Ring 128538+ 128538+ 128538+ POA
*
21a
Quad Ring, Upper Stem (qty 2 req) EPDM
116282+ 116282+ 116282+ POA
FKM
116283+ 116283+ 116283+ POA
24
* 29 O-ring, Flush EPDM
E70111 E70111 E70111 E70111
FKM
V70111 V70111 V70111 V70111
42 Stop Ring 122357+ 122357+ 122357+ 122357+
* Recommended Spare Parts
PL5027-CH155
*** See actuator parts lists
1. For items 8, 16, and 24, see W72RSP Mix Proof Seat Lift with External Flush Valve Stems Chart.
4. Unless otherwise noted, quantity required is 1.
6. POA = Part # on availability; N/A = not available with this design.
Contact Factory
***
Stem, Lower Assembly - See note 1, below
Stem, Upper Assembly - See note 1, below
Stem, Actuator - See note 1, below
