SPX W Series User Manual

Item # Part Description
4" Diameter
1
6" Diamete
r
1
8" Diamete
r
1
1 Indicator Stem - Visual 106050+ 107951+ POA
1a Indicator Stem - Control Top 106003+ 106004+ 110800+
4 Cylinder 106006+ 106007+ 128394+
* 5 Bearing, Indicator Stem
102757+ 102757+ 102757+
* 6 O-ring, Indicator Stem Nitrile
N70210 N70210 N70210
* 7 O-ring, Outer Yoke Nitrile
N70240 N70255 N70367
* 8 O-ring, Piston Nitrile
N70342 N70433 N70443
9 Cap Screw, 1/4-20 x .375" lg.
30-68
(qty 4 req)
30-68
(qty 8 req)
30-361
(qty 12 req)
10 Piston & Spring Assembly 106009+ 106010+ 129822+
* 11 O-ring, Yoke Nitrile
N70210 N70214 N70214
12 Yoke 1-1/2" Valve 106119+ -- --
107764+ -- --
-- 106120+ --
-- 106121+ --
-- 106118+ --
6'' V al ve -- -- 128396+
13 Vent Plug (see note 2) 3023957+ 3023957+ 3023957+
* 14 Bearing, Piston
101995+ 102052+ 100256+
* 15 Bearing, Yoke
102757+ 106047+ 106047+
18 Spring, Upper Stem 101946+ 5901106+ 5901106+
31 Washer (see note 3) 43-55 -- --
33
Elbow swivel 90°
78-157 78-157 78-157
4" Diameter
1
6" Diameter
1
8" Diameter
1
Visual Indicator Stem 1-1/2" ACT00188 -- --
2" ACT00122 -- --
2-1/2" -- ACT00279 --
3" -- ACT00280 --
4" -- ACT00281 --
6" -- -- POA
Note s:
PL5027-CH58
* Recommended Spare Parts
1.
2. Only required for valves without control top.
3. Item 31 is required on 1-1/2" valves only.
4. Unless otherwise noted, quantity required is 1.
Complete Actuator Assemblies
Part Description
Air-to-Raise
2" Valve
2 1/2" Valve
3" Valve
4" Valve
4-inch diameter actuator for 1-1/2inch and 2-inch valves; 6-inch diameter actuator for 2-1/2 inch
and 4-inch valves; 8" diameter for 6 inch valves.
Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 77
W71/W73 Non-Seat Lift Actuator
