Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 79
W71/W73 Seat Lift Actuator
Item #
4" Diameter
1
6" Diameter
1
8" Diameter
1
1 Indicator Stem - Visual 106050+ 107951+ POA
1a Indicator Stem - Control Top 106003+ 106004+ 110800+
4 Cylinder 111506+ 111491+ 123974+
* 5 Bearing, Indicator Stem
102757+ 102757+ 102757+
* 6 O-ring, Indicator Stem Nitrile
N70210 N70210 N70210
* 7 O-ring, Outer Yoke Nitrile
N70240 N70255 N70367
* 8 O-ring, Upper Seat Piston (qty 2 req) Nitrile
N70342 N70433 N70443
9 Cap Screw, 1/4-20 x .375" lg.
30-68
(qty 4 req)
30-68
(qty 8 req)
30-361
(qty 12 req)
10 Lower Seat Piston & Spring Assembly 113661+ 113660+ 129823+
* 11 O-ring, Adjustment Sleeve (qty 2 req) Nitrile
N70214 N70219 N70219
12 Yoke 1-1/2" Valve 109823+ -- --
109940+ -- --
-- 109928+ --
-- 109934+ --
-- 109905+ --
6'' Valve -- -- 128655+
13 Vent Plug (see note 2) 3023957+ 3023957+ 3023957+
* 14 Bearing, Main Piston
101995+ 102052+ 100256+
* 15 Bearing, Adjusting Sleeve
106047+ 109919+ 109919+
* 16 Bearing, Lifting piston
109820+ 109920+ 109920+
* 17 O-ring, Inner Yoke Nitrile
N70222 N70328 N70328
18 Spring, Upper Stem 101946+ 5901106+ 5901106+
19 Stop, Lifter 109817+ 109913+ 123998+
20 Adjusting Nut, Upper Seat Lift 109822+ 109918+ 122345+
* 21 Bearing, Lower seat piston
111044+ 101995+ 102052+
22 Main Piston 111510+ 111486+ 123979+
23 Upper Seat Lift Piston 111507+ 111489+ 124555+
24 Adjusting Sleeve, Lower Seat Clean 109821+ 109912+ 126834+
* 25 O-ring, Inner Lower Seat Piston Nitrile
N70216 N70219 N70219
* 26 O-ring, Adjusting Nut Nitrile
N80026 N80222 N80222
28 Bushing 112427+ 112517+ 112517+
* 29 O-ring, Outer Lower Seat Piston
Nitrile N70335 N70342 N70433
30 Quick Exhaust (avail. upon request) 114680+ 114680+ 114680+
31 Washer (see note 3) 43-55 -- --
33 Elbow swivel 90° 78-157 78-157 78-157
4" Diameter
1
6" Diameter
1
8" Diameter
1
Air-to-Raise Visual Indicator Stem 1-1/2" ACT00282 -- --
2" ACT00283 -- --
2-1/2" -- ACT00284 --
3" -- ACT00285 --
4" -- ACT00286 --
6" -- -- POA
Notes:
PL5027-CH60
* Recommended Spare Parts
1.
2. Only required for valves without control top.
3. Item 31 is required on 1-1/2" valves only.
4. Unless otherwise noted, quantity required is 1.
Part Description
4-inch diameter actuator for 1-1/2inch and 2-inch valves; 6-inch diameter actuator for 2-1/2 inch and 4-inch
valves; 8" diameter for 6 inch valves.
4" Valve
Part Description
2" Valve
2 1/2" Valve
3" Valve
Complete Actuator Assemblies
